Arc Welding Generator Manufacturer

Name: Arc Welding Generator Manufacturer
Brand: Werner
SKU: 131579121
Availability: InStock

US$ 500 - 1,000 MOQ: 50 Sets

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Werner

Model Number:

W5600IH

Werner (Fujian) Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Werner

Model Number W5600IH

Output Type AC Single Phase

Speed 3750

Frequency 50/60

Rated Power 1500W

Rated Voltage 230V

Rated Current 60-120A

Double use for welding and generating, compact and lightweight,small size.
Non-stop smooth electric arc is avalable for any welding
AC auxiliary current and DC welding current can be used simultaneously which improves the working efficiency and is convenient for operations.
Rare earth permanent magnetic digital inverter alternator to insure high efficiency and stable welding current.

Model Name	W5600IH
ENGINE
Engine	170F
Engine Type	4-stroke, OHV, single cylinder, cylinder inclined, air cooled,petrol
Displacement	212ml
Compression	8.5:1
Rated rev	3600r/min
Ignition system	T.C.I
Start system	Recoil hand-operated, electric system
Engine rated output	4200W
Fuel tank capacity	14L
Fuel comsumption	≤316g/kw.h
Lube Oil capacity	0.6L
AC Generator
Rated Output (KW)	1.5KW
Rated AC frequency	50/60HZ
Rated AC voltage	230V
Alternator	Werner permanent magnetic alternator,100%copper,brushless
Phase No.	singel phase
output waveform	pure sine wave
output efficiency	≤90%
Total Harmonic Distortion	≤1.5%
Frequency stability	±0.5Hz
Voltage regulation	0.5%V
DC Welder
Rated Max.current (A)	120A
Rated AC current	60-120A
Load voltage range	22-25V
No-load voltage	60-75V
Dimension	477×470×470 (mm)
Net weight	36.2KG
