Hatz Generator/dc Power Supply
US$ 6,000 - 8,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
WERNER
Model Number:
WN12HTZ
Payment & Shipping
Payment Methods:
Port of Shipment:
Fuzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Silent dc Generator Permanent MagnetUS$ 6,000 - 8,000MOQ: 1 Set -
12KW 60volt DC Generator From China SupplierUS$ 5,500 - 8,000MOQ: 1 Set
-
10KW/48V Diesel Air-cooled DC Charging GeneratorUS$ 6,000 - 8,000MOQ: 1 Set
-
10KW Diesel DC GeneratorUS$ 5,500 - 8,000MOQ: 1 Set
-
24 Volt dc Generator/DC PowerUS$ 360 - 430MOQ: 50 Sets
Place of Origin
Fujian, China
Brand Name
WERNER
Model Number
WN12HTZ
Output Type
DC
Speed
3000RPM
Frequency
DC
Rated Power
12KW
Rated Voltage
48V
Rated Current
250A
Specifications
Hatz generator/dc power supplyCompact and light weight
High efficiency
| DC charging generator powered by HATZ | ||
| GENSET MODEL | Open type model | WN12HTZ |
| Soundproof model | WN12HTZ/S | |
| Continuous output(kw) | 12KW | |
| DC Voltage(V) | 48V | |
| DIESEL ENGINE MODEL | 2G40 | |
| Engine Characters | Two-cylinder ,vertical 4-stroke,air-cooled,diesel | |
| Rated power/speed (KW/rpm) | 13.7kw/3000rpm | |
| 12.3kw/2500rpm | ||
| Bore(mm)xStroke(mm) | 92*75 | |
| Displacement(cc) | 997 | |
| Compression ratio | 20.5 | |
| Max. torque (N.M) | 50 /2000rpm | |
| Speed control (rpm) | idling speed | 1000rpm |
| steady state adjust rate | 5% at 3000rpm | |
| Lubricating system | Pressure splashed | |
| Cooling system | Forced air-cooled | |
| Fuel consumption rate (g/kw.h) Min/Max | 228/265 | |
| Lube oil capacity (L) Max/Min | 2.5/1.67 | |
| Starting motor | 12V-2.0KW,24V-3.0KW | |
| Charging system 3000rpm | 14V-23A,28V-12A,14V-55A,28V-27A | |
| Accumulator capacity (V.AH) Min/Max | 12V/45/88AH, 24V/45/88AH | |
| ALTERNATOR MODEL | W90AD | |
| Continuous output(kw) | 12 | |
| Power Efficiency | ≥90% | |
| Voltage Regulation | 48V-57V | |
| Wave form | DC Wave | |
| Max Current (A) | 250 | |
| Ripple voltage | ≤3mV | |
| Dimension(mm*mm*mm) Open/Soundproof | 700*500*820/1100*750*800 | |
| Standard features | ||
| Standard features | Voltage meter,Current meter,Oil pressure meter,temperature meter | |
| Automatic outage protection when there is AC component output | ||
| High temperature alarm outage protection | ||
| Low fuel level warning | ||
| Automatic current adjustment when rectifier module radiator temperature anomaly | ||
