ZPG Series drying machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Supply Ability 5 Set / Sets per Month
Port shanghai port
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	YIBU
Model Number	ZPD		Type	Grain Processing Equipment

Packaging Details

wooden case

Product Description

Specifications

Being adapted the big area heating way

ZPG Series liquid drier

Being adapted the big area heating way, its heat conducting area is large and its heat efficiency is high.
Being installed stirring in the machine, it makes raw material in cylinder form the state of continuous circle inside the cylinder, so the uniformity to be heated of raw material is raised greatly.
Being installed stirring in the machine, pulpinese, paste-like mixture or powder raw materials can be dried easy.

It is an innovation horizontal batch-type vacuum dryer. The moister of wet material will be evaporated by heat transmission. The stirrer with squeegee will remove material on hot surface and move in the container to form cycle flow. The evaporated moisture will be pumped by vacuum pump.

The following raw materials from pharmaceutical industry, foodstuff industry, chemical industry and so on can be dried.
Suitable for pulpiness, paste-like mixture or powder raw material.
Thermal sensitive raw material having the requirement to dry at lower temperature.
Raw materials that are easy to oxidize or explode and have strong irritative or toxic.
Raw materials that need to recover solvent.

Item		Model
Name	Unit	ZPD-500	ZPD-750	ZPD-1000	ZPD-1500	ZPD-2000	ZPD-3000	ZPD-5000
Working volume	L	300	450	600	900	1200	1800	3000
Over in the cylinder	Mm	600 × 1500	800 × 1500	800 × 2000	1000 × 2000	1000 × 2600	1200 × 2600	1400 × 3400
Stirring revolution	Rpm	5-25		5-12		5
Power	Kw	4	5.5	5.5	7.5	11	15	22
Design pressure of jacket	Mpa	≤ 0.3
Pressure in the cylinder	MPa	-0.09— -0.096

Note: The evaporated amount of water its related to the characteristics of raw materials and the drying temperature. With renew products unceasingly, the related parameter will be exchanged, it does not announce in advance, pardon!
