MC Series Plus Dust Filter With Cloth Bag
US$ 230,000 - 890,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Yibu
Model Number:
MC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
MC Series Plus Dust Filter With Cloth BagNegotiableMOQ: 1 Set -
Pulse De-duster With Cloth Bag Used in Building MaterialUS$ 2,320,000 - 8,980,000MOQ: 1 Set
-
MC Pulse De-dusterNegotiableMOQ: 1 Set
-
Pulse De-duster With Cloth Bag Used in Other IndustriesUS$ 50,000 - 90,000MOQ: 1 Set
-
MC Pulse De-duster With Cloth Bag Used in MachineUS$ 230,000 - 890,000MOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
Yibu
Model Number
MC
Type
Other, Deduster
After-sales Service Provided
Engineers available to service machinery overseas
Descriptions:
On the basis of MC-I spec, the square spec pulse dust filter with cloth bag MC-II is the amended and improved one. In addition to the advantages that I spec is high in the dust removing efficiency, big in the air capacity, stable in the performance, easy in operation and maintenance, MC-II has the better result than MC-I. Such as: it is not easy to build up the powder and its application is wide and so on. The device is widely used for the ventilation, dust removing and powder restoration in the grain, food, feed, metallurgical, chemical, building material, medical and other industries.
Technical parameters
| parametersspec | MC24 | MC36 | MC48 | MC60 | MC72 | MC84 | MC96 | MC120 | |
| Filtering area(m2) | 18 | 27 | 36 | 45 | 54 | 63 | 72 | 90 | |
| Filtering bag number(piece) | 24 | 36 | 48 | 60 | 72 | 84 | 96 | 120 | |
| Filtering air speed(L/m2.s) | 20-40 | 20-40 | 20-40 | 20-40 | 20-40 | 20-40 | 20-40 | 20-40 | |
| Filtering air volume(m3/h) | 1300-2600 | 1950-3900 | 2600-5200 | 3240-6480 | 3900-7800 | 4550-9100 | 5200-10500 | 6500-13000 | |
| Max. Overall dimension | L | 1000 | 1400 | 1800 | 2200 | 2600 | 3000 | 3560 | 4360 |
| W×H | 1450×3700 | 1450×3850 | 1450×4100 | ||||||
| Dust remover | Pulse valve number | 4 | 6 | 8 | 10 | 12 | 14 | 16 | 20 |
| Compressed air consumption m3 | 0.07 -0.30 |
0.11 -0.40 |
0.15 -0.50 |
0.18 -0.60 |
0.22 -0.60 |
0.25 -0.90 |
0.29 -0.90 |
0.37 -0.90 |
|
| Compressure air pressure (kg/cm2) |
5-7 | ||||||||
