Air Screw Compressor 37kw

Air Screw Compressor 37kw thumbnail-1
Air Screw Compressor 37kw photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw
Configuration:
Stationary
Contact Supplier Request Quote Chat Now
ZiQi Compressor (Shanghai) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or any port of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Screw
Configuration Stationary
Power Source AC Power
Lubrication Style Lubricated
Mute Yes
Place of Origin Shanghai, China
Brand Name Goodair
Model Number Inverter Air Screw Compressor 37kw GV-37A
Warranty 2years
After-sales Service Provided Engineers available to service machinery overseas

Specifications

inverter 37kw screw compressor
Germany technology and air end
imported main parts
good performance
super-quiet device

Air Screw Compressor 37kw / Inveter Screw Compressor



Detail Description

Air End:The Screw Rotor (the air end) is originally from Germany and applies the third generation,which is 5:6 dissymmetrical flute profile rotor.The tangent speed is 30-60m/s,much lower than the common compressor at 60m/s.There are 0.003 inch space between each rotor.This greatly decrease the backflow loss and can increase 10-20% of the efficiency and can save 20% of the electricity.The Sweden SKF bearing greatly extends the working life of the air end.

Controller:Advanced PLC program-mable logic controller,full auto run.Display Chinese or Engish,finger touch button and handle convenience.

Intake Valve:No spare parts design intake valve,ON-OFF adjustment method,air adjustment range 0-100%,pressure loss,action,long life,is the most reliable,most efficient air intake adjustment method.

Electrical Componments: Siemens,using sliver contacts,life of up to 300 million times over the safe use have long-term security.

Motor:Using well-known brand-phase high-performance motor,protection calss IP54,insulation class F-class,with "SKF" heavy bearings,transmission efficiency is as high as 95% or more,good insulation,high temperature resistance,long life.

Air and Oil separator elements:The high-efficiency separator will reduce compressor oil carryoverand power consumptions oil carryover is only 1-2ppm.

Inlet pressure controller,solenoid valve:Pressure reach to upper limit the pressure controller automatically disconnect the circuit,the pressure reaches the low limit of auto closed circuit;Through solenoid valve,gas off replace electric off;Product precise,reliable and stable.



Technology Data:

Mode

GV-22A
GV-30A
GV-37A
GV-45A
GV-55A
GV-75A
Free air deliver/Discharge Pressure
M3/min/Mpa
3.80/0.7
5.20/0.7
6.82/0.7
7.42/0.7
10.83/0.7
14.11/0.7
3.62/0.8
5.01/0.8
6.24/0.8
7.11/0.8
9.2/0.8
13.2/0.8
3.21/1.0
4.52/1.0
5.74/1.0
6.22/1.0
8.61/1.0
12.04/1.0
2.80/1.2
3.83/1.2
4.93/1.2
5.65/1.2
7.71/1.2
10.06/1.2
No of compressor stage

Single stage
Ambient temperture
°C
-5~+45
Cooling Model

Air-Cooling
Displacement temperture
°C
<Ambient temperature +40°C
Noisc level

65±2
65±2
68±2
68±2
68±2
72±2
Drive method

Frequency conversion
Electricity
V/ph/Hz
380/3/50
Motor Power
Kw
30
37
45
55
75
90
Starting method

Frequency conversion start
Lubricant
L
15
22
22
22
50
50
Dimension
L(mm)
1725
1725
1915
1915
2350
2350
W(mm)
930
930
1090
1090
1230
1230
H(mm)
1555
1555
1635
1635
1820
1820
Weight
Kg
1020
1070
1350
1420
2050
2120
Air Outlet Pipe Diameter
Inch
G1 1/4”
G1 1/4”
G1 1/2”
G1 1/2”
G2”
G2”



We GoodAir Group will provide users with high-quality compressed air in order to enable users to achieve the best capacity. Users can range in our products, choose a complete set of compressed air systems to meet the various needs.

Please feel free to contact me now for further information.
