Help Center380V Textile Industry Portable Electric Screw Air Compressor Specification
Related Products
-
15bar Belt Drive Textile Industrial Screw Air CompressorUS$ 1,969 - 2,727MOQ: 1 Unit -
New Chian Frequency Interver Air Compressor Products for SaleUS$ 2,380 - 36,590MOQ: 1 Set
-
Low Noise Air Compressor Industrial for SaleUS$ 2,380 - 36,590MOQ: 1 Set
-
Electric Screw Air Compressor 1 Mpa for SaleUS$ 2,380 - 36,590MOQ: 1 Set
-
Dealership Potable Dental Oil Free Scroll Air Compressor 3phUS$ 10 - 6,000MOQ: 1 Set
Advantage:
1,Durable
2,Environmental Protection
3,Economical
4,Useful
5,GHH Host from Germany,WEG IE4 MAIN MOTOR from Brazil
6,High Efficiency
7,Energy Saving
Compressor Brand:ZIQI
Compressor Name:GAS-18.5A
Technical Specifications:
Air Displacement m³/min |
0.32-3.2 | Color |
Blue |
Exhaust Pressure MPa |
0.7 |
Cooling Method |
Air-cooling |
Power(KW) |
18.5 | Transmission |
Belt Drive |
Net Weight(KG) |
600 | Configurations |
Stationary |
Dimensions(mm) |
1260*850*1220 |
Starting Method |
Frequency Start |
Voltage |
380V | Noise dB(A) | 6 |
Compressor Configuration:
The host is a core part of the screw-type air compressors. Host originally designed: reliable quality, stable performance and high operating efficiency
WEG motor(Nantong factory)seat serial no. 280S/M,the length 90cm,weight 891kg,WEG head office locate in Jaragua do Sul. Brazil, 2011 global turnover of 3.657 billion dollars, 26 plants in 11 countries around the world, the annual worldwide production of more than 55,000 motor, is one of the world's largest motor manufacturer.
Oil tube Adopt the ZIQI compressor exclusive locked technique, no oil leakage. Selection of Italy Manul high pressure tubing, 5 times longer than ordinary tubing life.
Paper washer Brand :The United States SEALTEX Adopt the non asbestos material , mechanism, high temperature resistant, oil resistant , anti corrosion.
Coupling Combined the host with motor together, high transmission efficiency with durable operation
Number |
Spare Parts Name |
Quantity |
|
|
1 |
Air End |
1 |
piece |
ZIQI Custom |
2 |
IE4Motor |
1 |
piece |
Brazil WEG(Nantong Factory) |
3 |
Host,Motor bearing |
1 |
piece |
Sweden SKF |
4 |
Air Filter Core |
1 |
piece |
ZIQI Custom(Germany Filter Material) |
5 |
Oil&Air Separator Core |
1 |
piece |
ZIQI Custom(Germany Filter Material) |
6 |
Oil Filter Core |
1 |
piece |
ZIQI Custom(Germany Filter Material) |
7 |
Minimum Pressure Valve |
1 |
piece |
ZIQI Custom |
8 |
Fan |
1 |
piece |
ZIQI Custom |
9 |
Oil&Air Radiator |
1 |
piece |
ZIQI Custom |
10 |
Safety Valve |
1 |
piece |
Shanghai Yuejin |
11 |
Magnetic Valve |
1 |
piece |
ZIQI Custom |
12 |
Air Valve |
1 |
piece |
ZIQI Custom |
13 |
Screw Air Compress Oil |
1 |
piece |
ZIQI Custom(UK) |
14 |
Pressure Sensor |
1 |
piece |
ZIQI Custom |
15 |
Temperature Sensor |
1 |
piece |
ZIQI Custom |
16 |
Thermal Valve |
1 |
piece |
ZIQI Custom |
17 |
Pipeline |
1 |
set |
Italian Manuli Hydraulic Material(Suzhou)Co,ltd |
18 |
Electric Apparatus |
1 |
piece |
Schneider |
19 |
Oil Cylinder |
1 |
piece |
AIkang (Shanghai) Pressure Container Co,ltd |
20 |
Coupling |
1 |
set |
ZIQI Custom |
21 |
Paper Washer |
1 |
set |
US SEALTEX |
Packaging:Plywood Packaging
Our packaging is strict and careful to make sure the goods intact
Shipping:Shipped in 5 days after payment
Our shipment is fast and secure.
THE SEVEN STAR BUTLER SERVICES
Our services promise you:
We provide the best and reasonable design and formula of compressor for you.
We provide the fastest and all-round feedback of problems of our product for you.
We provide the most professional and considerate technical support for you.
Established in 2007,ZiQi Compressor (Shanghai)Co.Ltd is located in the new district of Pudong of Shanghai.We are the professional producer of compressor making all kinds of compressors.We have our own intellectual property.And we provide excellent formula for the product for you.We have a passionate and professional team to assure our product and service perfect and towering.Your need is our meaning of existence.Your satisfaction is our most valuable prize .Your trust is our living foundation.We increasingly move forward,improve our products and transcend ourselves.Your wisest decision is cooperating with us we believe.Thanks for knowing and visiting us.You are welcomed by us every time.
Q:Are you factory or trading company?
A:We are professional producer of compressor in China
Q:How many machine can you produce per month?
A:1000sets
Q:What is your quality of compressor?
A:Good as Atlas and Ingersoll rand
Eason Li
ZIQI Compressor Co,Ltd
New Add: No.28#16 Hangming Road,Damaiwan industry Park,Pudong New Arae,Shanghai China
Tel:+86(0)21-68148281 Fax:+86(0)21-68148280
Mobile: +86 15821086852
We will not allow each small problems happen in our products.We focus on every detail to make our product best given to our customers.Before the product delivered to the customers,we will examine every detail ,from the examination of a screw to that of the outward appearance.We will not escape every little detail.
Test of Machine
