Specifications
High Volume Low Pressure Air Compressor1.Germany original GHH brands air end
2.Super motor
3.Energy-saving
Low pressure screw compressor series is a new compressor produced according to the national policy of energy saving, emission reduction and environment protection. it changes the traditional compressor with relatively high pressure. it transfers the compressor air after pressure reduction to the air consumer,which wastes large amounts of energy.The low pressure screw compressor canbe distributed according to the air pressure of the user, to satisfy the process flow with minimum energy. the manufecturing cost of your product can be largely improved.
| type | Volume flow |
pressure | power(kW) | speed | size(mm) | weight(kg) | air volume(m³) | exist diameter | |
| GAL-37A | 5.0 | 7.9 | 37 | 2945 | L | 1595 | 980 | 145 | 11/2” |
| 4.0 | 8.3 | ||||||||
| 3.5 | 8.5 | M | 1000 | ||||||
| 3.0 | 8.7 | H | 1365 | ||||||
| GAL-55A | 5.0 | 12.6 | 55 | 2965 | L | 2100 | 1250 | 220 | 2” |
| 4.0 | 13.0 | ||||||||
| 3.5 | 13.2 | M | 1250 | ||||||
| 3.0 | 13.4 | H | 1700 | ||||||
| GAL-90A | 5.0 | 18.5 | 90 | 2965 | L | 2100 | 2100 | 270 | 2” |
| 4.0 | 20.0 | ||||||||
| 3.5 | 20.2 | M | 1250 | ||||||
| 3.0 | 20.4 | H | 700 | ||||||
| GAL-110A | 5.0 | 21.5 | 110 | 2975 | L | 2545 | 2580 | 420 | DN65 |
| 4.0 | 26.0 | ||||||||
| 3.5 | 26.5 | M | 1450 | ||||||
| 3.0 | 27.0 | H | 1900 | ||||||
| GAL-132A | 5.0 | 27.0 | 132 | 2975 | L | 2545 | 2750 | 460 | DN65 |
| 4.0 | 28.5 | ||||||||
| 3.5 | 29.0 | M | 1450 | ||||||
| 3.0 | 29.5 | H | 1900 | ||||||
If you chose us, you are bound to have the most advance screw technology and the best service of the world.
ziqi provide high quality produces and services for generall industrials , manufacture industrials electricity, architecture, mining, energy, ect, our service network composed of distributors and agencies assigned by local subsidiaries , they are providing perfect services for ZIQI's customers from all over the world.
ZIQI Group:
Provide the best compressed air system to user
Our Products:
High efficient, durable, energy saving, enviroment protection
If you have any questions, please feel free to contact me. Thanks
