Free Design 10KW Off Grid Solar Panel PV System with Controller Battery Inverter Mounting System and Cables
- Stand-alone power supply, independent, reliable and stable.
- Various options from 300w up to 10kw solar panel capacities.
- Customized design and solution are available.
- Long service time, little maintenance, environment friendly.
- Professional technical guidance, knowledge training and relevant necessary after-sale service.
System Basic Information: |
Solar Panel Rated Output Power: |
10KW |
|
|
Solar Panel
|
Type: Polycrystalline Silicon PV Module |
QTY: |
40 pcs |
PV Array Combiner |
Simplify wiring between PV array and controller, |
QTY: |
1 pc |
Controller |
PV Charging Controller 96V 100A; PMW charging type, LCD display, intelligent control. |
QTY: |
1 pc |
Inverter (UPS type) |
Rated DC96V input, AC220V 1-phase output |
QTY: |
1 pc |
Battery |
12V/200AH per piece |
QTY: |
32 pcs |
Solar Panel Rack |
Roof type mounting rack |
QTY: |
1 set |
Cables |
International standard, with specification suitable for solar system, RVV series |
QTY: |
100m |
Connectors |
3-terminal connectors, used for panels connection in parallel |
QTY: |
10 pcs |
Unity supply complete pack with optimum system configuration to satisfy clients’ any customized requirements, including options from 300w up to 10kw solar panel capacities to meet various power demands. Customized design and solution are also available based on actual climate condition, we can also provide professional technical guidance, knowledge training and relevant necessary after-sale service.
System Working Principle:
This is an off-grid system which uses batteries to store the solar energy, at the same time, the system can be connected with the grid for utilization of grid power. The system uses battery power in priority, but when sunshine is not so good or loads consumption is too big which caused the battery power inadequacy, then the system can switch automatically to grid power supply. Meanwhile, the system can charge the batteries with grid power until batteries are fully charged. Then the system will switch back to battery power supply.
Notes:
1. Pictures shown are for reference.
2. Power output data is based on areas with daily average peak power sunshine of 4~4.5hrs.
3. The battery capacity is designed for power storage of 1~1.5 days daily power consumption.
4. Solar panel rack can be specially designed based on site condition and customized requirement.
