Wanshen HDZ 100D Automatic packaging machinery
Main Application
The equipment is mainly used for automatic packing of products with thin-sheet (thickness ≥ 1mm) and many varieties and many specifications of products. The kind of machine is mainly to solve the packing of products which difficult to sub boards and having many species in a box.
Main characteristics
1. The speed is regulated by variable frequency and adopts automatic control system.
2. The machine adopts human-machine interface operating system, automatically display box speed, quantity and other performance parameters, and also display the fault causes and methods of operation and maintenance.
3. It can be implemented that adjust and use of more specifications at the specific confine on the same machine.
4. Manual and automatic conversion
5. It can be simultaneously completed that the folding of instructions and cartoning.
6. It can print three batch numbers on the box, and also have the functions of print serial number in addition(option).
7. Incorporates automatic inspection system and has the functions of automatic suspension and removal of non-conforming products if lack of material .
8.It can be installed with hot melt adhesive machine.(option)
Main Technical Parameters
Speed |
Specifications of the paper carton: |
Specifications of the manual: |
50-80boxes/min |
(110mm-160mm)*(70mm-135mm)*(12mm-55mm) |
(110mm-160mm)*(90mm-250mm) |
Power |
Total Power |
Equipment dimensions |
380V.50HZ |
1.5kw |
2700mm*1120mm*1550mm |
Compressed air pressure |
Compressed tolerance |
Weight |
0.6Mpa |
50-150l/min |
1100kg |
Weight of Manual |
Weight of Carton |
|
40-80g/m2 |
250-400g/m2 |
