water jet cutting machine for seals cutting
- 10 Set / Sets per Month
- Shanghai Qingdao
- T/T Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Gold selection equipment Mobile gold cart Job site
- DOING photovoltaic solar panels recycling production line
- Stainless Steel Double Kitchen Sink Middle Weld Seam Rolling Machine
- Stainless steel handmade sink hydraulic power of light direct press
- Stainless steel handmade sink R corner press machine Electrical box R corner press machine
Product Details
Brand Name: | MUNAN CNC | Model Number: | MN4235-NC3020 | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1. water jet cutting machine for seals cutting2. American technology and parts
3. Good after sales service
water jet cutting machine for seals cutting
Model | MN4235(fly arm) | MN4235(bridge type) | ||||||
Picture | ||||||||
Describe | 1313 | 1515 | 1520 | 1525 | 1530 | 2030 | 2040 | 2060 |
1.3x1.3m | 1.5x1.5m | 1.5x2.0m | 1.5x2.5m | 1.5x3.0m | 2.0x3.0m | 2.0x4.0m | 2.0x6.0m | |
MN4235 intensifier pump | ||||||||
One set of 3-axis cutting head | ||||||||
PC based CNC controller and cabinet | ||||||||
Automatic abrasive deliver system | ||||||||
Pump oil Cooling system | ||||||||
Water softener | ||||||||
One set of tool and spare parts kit | ||||||||
Auto CAD software | ||||||||
One year warranty |
Option |
Upgrade original KMT intensifier |
Automatic sludge removal system |
4th axis cutting head |
Double cutting head |
Warranty | Provide life-long service, free upgrades, warranty period is one year. |
Term of delivery | Delivery for 15-20 days after received deposits |
Installation & Training | needed to first pay round trip and responsible accommodation for during the installation (two members) |
Payment terms | T/T 30% advance, after the 70% delivered will be arrange shipment. |
Validity of offer | First come, first served basis |
Commitment | After the installation training, guarantee the customer can independent programming and independent operate |
Package | Thick plastic thin film simple packaging and container. |
intensifier pump | ||
Model | MN4235 | MN4238 |
Intensifier | Accustream from USA | KMT from German |
Continuous working pressure | 350MPa | 380MPa |
Supercharge ratio | 20:1 | |
Max water discharge | 3.8L/min | |
Water supply pressure | ≥0.2MPa | |
Oil pump displacement | 80ml/rpm | |
Max discharge of oil pump | 120L/min | |
Oil pump pressure | 31.5MPa | |
Hydraulic oil tank capacity | 46#/320L | |
Max diameter of orifice | 0.35mm | |
Main motor power | 37kw | |
Power supply | 380V 50Hz | |
Weight | 1200kgs | |
Overall dimension | 1700x1000x1450mm | |
Main motor | Siemens | |
PLC | Siemens | |
Heat exchanger | Water/oil panel cooler | |
Control system | LP/HP auto control | |
Pressure-Temperature display | Digital temperature display | |
Proximity sensor | Original imported from Switzerland | |
Auto alarming and shut-down | Over-temperature,excessive pressure,water shortage |
Specifications of cutting table -NC2015 | ||||
Model | fly arm | bridge type | ||
picture | ||||
Structural style | Fly arm | Gantry | ||
Z travel | 150mm | |||
Control accuracy | 0.002mm | |||
Cutting accuracy | 0.1mm | |||
Reposition accuracy | 0.02mm | |||
Servo motor | X:2.3kw;Y:1.6kw;Z:0.5kw | X:0.75kw;Y-1.5kw;Z-0.5kw | ||
Linear guide | PMI | |||
Ball screw | PMI | |||
X,Y axis | Steel tube and cast iron | Aluminum | ||
Water tank | Coated stainless steel |
Specifications | Quantity | |
Assembled CNC frame,working table with water tank | 1 | |
CNC controller(cabinet,industrial pc,17’’ LCD | 1 | |
Intensifier pump (37kw 420MPa) | 1 | |
High pressure pipe&3 axis cutting head | 1 | |
Auto Abrasive feeding system | 1 | |
Water cooling tower | 1 | |
Water softener | 1 | |
Maintenance tools and banners | 1 | |
Spare parts | Gemstone orifice | 10 |
nozzle | 5 | |
Oil seal | 5 | |
Hp seal | 5 | |
Outlet poppet | 2 | |
HP seat | 2 | |
Poppet spring | 2 | |
Inlet poppet | 2 | |
Inlet poppet housing | 2 | |
Check valve repair kit | 1 | |
Blue goop | 1 |
