Specifications
DX2000-II Soldering Fume Extractor1.Easy install, absorbe effectively, low noise
2. LED alert function as tube blocked
Features of DX2000-II smoke purifying filter:
1,Integrated body design, structured with metal framework and processed with electrostatic spraying for premium cold-rolled steel sheet, is corrosion-resistant, environment-friendly and durable.
2,Four-stage purification design: filtering step by step enables harmful smoke to be better purified. Even for objects at least 8 times smaller than PM2.5, the purification rate can reach up to 99.97%.
3,This product has the 1.4m universal smoke suction arm, which can be positioned and oriented arbitrarily (its length may be regulated according to customer requirements, without the support of external force). (A patent application has been filed.)
4,Adopt DC brushless motor that has stable performance and long service life. Low noise, high efficiency, low energy consumption, zero maintenance and zero consumable.
5,CE and PONY certified, safe and reliable.
Operating-Principle Diagram of smoke absorber:
1.(Smoke, dust, powder)
→
2. Primary filtering (Large particles of oxides)
→
3. Medium- efficient filtering (About 50um particle oxides)
→
4. High-efficient filtering (About 0.3 um small particle oxides)
→
5. Clean air
Specification parameters of smoke absorber:
Inlete |
voltage |
power |
Filtering effect |
Noise |
Systemic flow |
Contour dimension |
Weight |
φ75mm |
AC 110-220V |
330W |
0.3μm99.97% |
<70dB |
430m³/h |
430X320X555 |
15Kg |
Any questions, pls feel free to contact me :
Kingsom Technology CO., LTD.
Contact: Danni
Tel:86-755-83045048/83645461 Fax:86-755-83045056
Phone:+86-18665374939
Skype:kingsomtech.
QQ: 2728428385
Address:Room 1013, 10th Floor, Hua Neng Bldg.,No.2066th Shen Nan Central Rd.,Fu Tian District, Shenzhen China
