Electric sightseeing car-JDG06+2
esigned for the tourist attractions, parks, large-scale amusement park, a gated community, campus, garden style hotels, resorts, villas, urban pedestrian street, port and other regional development of self driving tour, patrolling the area, walking special environmental protection type electric passenger vehicles.
| Model | Unit | JDG06+2 | ||
| Seat number | seat | 8 | ||
| Main dimension | length * width * height | mm | 4160*1180*1900 | |
| Wheelbase | mm | 3150 | ||
| Tread | Front wheel | mm | 870 | |
| The rear axle | mm | 980 | ||
| Minimum ground clearance | mm | 100 | ||
| Overall weight | kg | 680 | ||
| Maximum loading capacity | kg | 790 | ||
| Maximum speed | Km/h | 25 | ||
| Max grade ability | % | ≥25 | ||
| Minimum turning radius | m | ≤4.2 | ||
| Braking distance | m | ≤4.0 | ||
| Mileage (Road) | Km | ≥60 | ||
| Main configuration | ||||
| import standard | import standard | |||
| Controller (CURTIS) | 48V/300A | 1266 | ||
| Battery (USA T-875 TROJAN) | 8V/170AH | |||
| Motor(USA KDS) | Rated power | 4.0KW | ||
| Rated voltage | 48V | |||
| Rated speed | 2800/min | |||
| Excitation mode | separately excited | |||
| Battery charger | 48V25A | |||
| Tyre USA(Calle) | 18×8.50-8 | |||
| Lighting and signal | Combined lamp with front and rear (including brake lights)optional |
|||
| Note | Hydraulic frame, Hydraulic rear axle | |||
Shanghai Cheuk's Logistics Technology Co., Ltd.,which is subordinate to Cheuksgroup, is specializing in the developing, manufacturing and marketing of logistics, lifting and hydraulic machinery. We have abundant product line, forklift truck, pallet truck, stacker, table lift, tail gate, tow trackor, aerial work platform,plastic hand truck, hydraulic tools
and so on.
Our sales and network covers all over the world, also R&D center in Germany and America. We keep a really good relationship with our abroad partners. We based in China, supply you with our standard products of reliable quality, reasonable price. Also,the OEM service is available according to your requirements. Give us an opportunity, we will "Lifting your future"!
