Competitive price Tow Tractor QD series
- 10000 Set / Sets per Month
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | Cheuks | |
| Model Number | QD | After-sales Service Provided | No overseas service provided |
Product Description
The Product intro of Electric Tow tractor QD series
This tow tractor uses stepless speed regulating system controlled by MOS tube and is highly efficient and energy saving.
The motor driven tow tractor can be divided into stand-on type and sit-on type.
It is comfortable for the operator to drive this truck.
Characterized by high carrying capacity, this tow tractor is an important carrier for conveying
luggage or cargoes in airports, railway stations, factories, and postal services, etc.
Driven by electric motor, tow tractor can pull several loaded trolleys.
With traction capacity of 3000kgs to 5000kgs, the tow tractor is mainly used to transport large amounts of goods in a workshop or among workshops.
The specifications of electric Tow tractor QD series
| Model | Unit | QD-30BH | QD-50B | |
| Trailing load | kg | 3000 | 5000 | |
| Pulling motor | w | 2000 | 3000 | |
| Pulling speed | kw/h | 0-6.5 | 0-7 | |
| Drive style | Dual rear wheel driving system | Front wheel driving system | ||
| Speed control | stepless speed regulating system | |||
| Accumulator | 24V-D-300Ah | 36V-D-300Ah | ||
| Service time, for reference | 6 | 6 | ||
| Operation mode | sit-on type | sit-on type | ||
| Turning load | mm | 1350 | 1580 | |
| Tyre | green tyre | green rubber | ||
| Tyre size | front | φ267*76 | φ330*165 | |
| rear | φ330*114 | φ267*127 | ||
| Overall dimensions | mm | 1700X820X1240 | 1760X820X1280 | |
