Home > Products > Tow Tractor > Competitive Price Tow Tractor QD Series
Competitive Price Tow Tractor QD Series
- Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | Cheuks | |
| Model Number | QD | After-sales Service Provided | No overseas service provided |
Product Description
The Product intro of Electric Tow tractor QD series
This tow tractor uses stepless speed regulating system controlled by MOS tube and is highly efficient and energy saving.
The motor driven tow tractor can be divided into stand-on type and sit-on type.
It is comfortable for the operator to drive this truck.
Characterized by high carrying capacity, this tow tractor is an important carrier for conveying
luggage or cargoes in airports, railway stations, factories, and postal services, etc.
Driven by electric motor, tow tractor can pull several loaded trolleys.
With traction capacity of 3000kgs to 5000kgs, the tow tractor is mainly used to transport large amounts of goods in a workshop or among workshops.
The specifications of electric Tow tractor QD series
| Model | Unit | QD-30BH | QD-50B | |
| Trailing load | kg | 3000 | 5000 | |
| Pulling motor | w | 2000 | 3000 | |
| Pulling speed | kw/h | 0-6.5 | 0-7 | |
| Drive style | Dual rear wheel driving system | Front wheel driving system | ||
| Speed control | stepless speed regulating system | |||
| Accumulator | 24V-D-300Ah | 36V-D-300Ah | ||
| Service time, for reference | 6 | 6 | ||
| Operation mode | sit-on type | sit-on type | ||
| Turning load | mm | 1350 | 1580 | |
| Tyre | green tyre | green rubber | ||
| Tyre size | front | φ267*76 | φ330*165 | |
| rear | φ330*114 | φ267*127 | ||
| Overall dimensions | mm | 1700X820X1240 | 1760X820X1280 | |
Shanghai Cheuk's Logistics Technology Co., Ltd.,which is subordinate to Cheuksgroup, is specializing in the developing, manufacturing and marketing of logistics, lifting and hydraulic machinery. We have abundant product line, forklift truck, pallet truck, stacker, table lift, tail gate, tow trackor, aerial work platform,plastic hand truck, hydraulic tools and so on.
Our sales and network covers all over the world, also R&D center in Germany and America. We keep a really good relationship with our abroad partners. We based in China, supply you with our standard products of reliable quality, reasonable price. Also,the OEM service is available according to your requirements. Give us an opportunity, we will "Lifting your future"!
