90QJ4 quality stainless steel impeller submersible pump
>> Applications
For water supply from wells or reservoirs.
For domestic use,for civil and industrial applications.
For garden use and irrigation.
>> Operating conditions
Maximum fluid temperature up to +35°C.
Maximum sand content: 0.25%.
Maximum immersion :80m.
Minimum well diameter: 4".
>> Motor and Pump
Rewindable motor or Full obturated screen motor
Three-phase: 380V - 415V/50Hz
Single-phase:220V - 240V /50Hz
Equip with start control box or digital auto-control box
Pumps are designed by casing stressed
Curve tolerance according to ISO 9906
>> Options on request
Special mechanical seal
Other voltages or frequency 60 Hz
Single phase motor with built-in capacitor
>>Warranty: 1 year
(according to our general sales conditions).
>>Features
1. CS, GS, RoHS certificated.
2. 100% copper wire, stainless steel shaft, brass/cast iron outlet.
3. Wide voltage range design, single-phase and three-phase.
4. Strict complete testing for each product.
5. Dedicated sales representitives.
>>Materials
Components |
Material |
Pump external casing |
AISI 304 SS |
Delivery casing |
(1) Cast-Cu ASTM C85500 (2) AISI 304 SS |
Suction lantern |
(1) Cast-Cu ASTM C85500 (2) AISI 304 SS |
Diffuser |
Plastic. PC |
Impeller |
Plastic. POM |
Shaft |
(1) AISI 316 SS (2) AISI 304 SS |
Shaft coupling |
(1) AISI 316 SS (2)AISI 304 SS |
Wear ring |
AISI 304 SS & Ceramic |
Motor external casing |
AISI 304 SS |
Top cover |
(1) Cast-Cu ASTM C85500 |
Bottom support |
AISI 304 SS |
Mechanical seal |
Special seal for deep well(Graphite-Ceramic/TC) |
Shaft |
AISI 303 SS-ASTM 1045/5140 |
Bearing |
NSK |
Seal lubricant oil |
Oil for food machinery and pharmaceutic use. |
>>Certificates
Q: Can you do OEM?
A: Yes.
Q: How about the MOQ?
A: Generally, it is 50 PCS for each model.
Q: How about the lead / delivery time?
A: Usually 35 days. But it varies in Peak season.
Q: How about the warranty?
A: 1 year.
Q: Have your pumps got certificates?
A: Yes, We got CE, GS, RoHS, ISO2008.
