1/3 Sony CCD 520TVL Box Camera (2 Year Warranty)

Name: 1/3 Sony CCD 520TVL Box Camera (2 Year Warranty)
Brand: MAXVI/OEM
SKU: 131432915

US$ 15 - 45 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

MAXVI/OEM

Model Number:

ES500-MV-A62E

Enxun Digital Technology (Shenzhen) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen/HK

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name MAXVI/OEM

Model Number ES500-MV-A62E

Type Other, Analog Camera, Video Camera/Box Camera

Style Box Camera

Sensor CCD

Technology Infrared

Special Features Other, Eclipse function

Specifications

1/3 SONY CCD, 520tvl box camera;
0.5 lux DC12V;
Pal/NTSC Standard;
2 years Warranty

1/3 SONY 540TVL Box Camera(ES500-MV-A62E)

Model	ES500-MV-A62E	ES500-MV-A64E	ES500-MV-A84E
Image sensor	1/3SONY SUPER HAD CCD	1/3SONY SUPER HAD CCD	1/3SONY EX-VIEW HAD CCD
Effective Pixels	PAL:500(H)X582(V)	PAL:752(H)X582(V)	PAL:752(H)X582(V)
Effective Pixels	NTSC:510(H)X494(V)	NTSC:768(H)X494(V)	NTSC:768(H)X494(V)
Sensing area	3.6mmX2.4mm	4.8mmX3.6mm	4.8mmX3.6mm
Signal System	PAL/NTSC	PAL/NTSC	PAL/NTSC
Horizontal Resolution	420TVL/420TVL	520TVL/520TVL	520TVL/520TVL
Lens Mount	CS/C Mount adaptor option	CS/C Mount adaptor option	CS/C Mount adaptor option
Auto Gain Control	On/Off SelectableOSD	On/Off SelectableOSD	On/Off SelectableOSD
BackLight Compensation	On/Off SelectableOSD	On/Off SelectableOSD	On/Off SelectableOSD
S/N ratio	More than48db(AGC OFF)	More than48db(AGC OFF)	More than48db(AGC OFF)
Minimum illumination	0.05Lux/F1.2	0.08Lux/F1.2	0.08Lux/F1.2
Electronic Shutter	Distinguishingly Electronic Shutter	Distinguishingly Electronic Shutter	Distinguishingly Electronic Shutter
AutolrisLens	VIDEO/DC switchableOSD	VIDEO/DC switchableOSD	VIDEO/DC switchableOSD
Sync System	Internal Sync	Internal Sync	Internal Sync
Video Output	1.0Vp-p,75Ω(BNC)	1.0Vp-p,75Ω(BNC)	1.0Vp-p,75Ω(BNC)
Power Consumption	120mA	170mA	170mA
Operation temperature	-10-50	-10-50	-10-50
Power supply	DC12V/AC24V	DC12V/AC24V	DC12V/AC24V
Dimensions	115mm×59mm×54mm	115mm×59mm×54mm	115mm×59mm×54mm
