Help Center1/3'' Sony Super Had Ccd 700tvl Box Ccd Camera With OSD
Related Products
-
1/3 Sony Super Had Ccd 540tv Lines Box Camera Wide Dynamic Range(WDR)US$ 40 - 60MOQ: 10 Pieces -
1/3 Sony Super Had Ccd 480tvl Color Box Camera With Auto-IrisUS$ 40 - 60MOQ: 10 Pieces
-
High Sensitity 700TVL WDR Camera,digital Zoom With Osd MenuUS$ 40 - 60MOQ: 10 Pieces
-
1/3" Sony Security Camera,420TVL With Auto-IrisUS$ 40 - 60MOQ: 10 Pieces
-
Box CameraNegotiableMOQ: 50 Pieces
Specifications
1.1/3'' sony super had ccd 700tvl box ccd camera;2.Auto-Iris controlled by DC;
3.RS-485 Communication Control;
4.CE,RoHs,FCC
1/3'' sony super had ccd 700tvl box ccd camera with OSD ;
Specification:
| Specification: | ||||||||||
| Model | ES500-MV-F62C/A | |||||||||
| Signal System | NTSC | PAL | ||||||||
| Effective Pixels | 768(H)*494(V) | 752(H)*582(V) | ||||||||
| Image Sensor | 1/3 inch High sensitivity CCD | |||||||||
| Video Output | 1.0Vp-p Composite Signal(75 ohms) | |||||||||
| Sync.System | Internal Sync | |||||||||
| S/N Ratio | 52dB Min.(AGC off) | |||||||||
| Hori. Resolution | 700TVL | |||||||||
| Min. Illumination | 0.05LUX/0.0002 LUX(sense up auto) | |||||||||
| Brightness | 0~100 | |||||||||
| Shutter | AUTO/OFF/A.FLK/(X2~X512)/(1/90000~1/160) | |||||||||
| DSS | OFF/AUTO( X2~X128) | |||||||||
| 3D-NDR | ON/OFF(0~63) | |||||||||
| White Blance | ATW/PUSH/MANUAL | |||||||||
| AGC | OFF/LOW/MID/HIGH | |||||||||
| WDR | Up to 60dB(LOW/MIDDLE/HIGH) | |||||||||
| BLC | LOW/MID/HIGH | |||||||||
| ECLIPSE | ON/OFF(16 Zones) | |||||||||
| Stabilizer | ON/OFF | |||||||||
| Digital ZOOM | X1.00~X6.13 | |||||||||
| Day&Night | AUTO/DAY/NIGHT/EXT/IRED | |||||||||
| Night Burst | ON/OFF | |||||||||
| Motion Detection | ON/OFF(4 Programmable Zone) | |||||||||
| Privacy | ON/OFF(8 Programmable Zone) | |||||||||
| D-EFFECT | V-FLIP/MIRROR/ROTATE | |||||||||
| Sharpness | 1~100 | |||||||||
| Baud Rate | 4800/9600/19200/38400/57600 | |||||||||
| OSD Language | ENG/KOR/RSN/CHN/SPN/PRN | |||||||||
| Applicable Lens | DC iris/Manual Lens | |||||||||
| Supply Voltage | 12V DC(+10%~20%) | |||||||||
| Power Consumption | 2.4W(Max) | |||||||||
| Oper.Temp./Humidity | ‘-10°C~50°C(14°F~122°F)/30%~80% RH | |||||||||
| Stor. Temp./Humidity | ‘-20°C~60°C(-4°F~140°F)/20%~90% RH | |||||||||
Our service:
1.warranty is two years.
How to order from us |
|
1. Please confirm the model numbers and quantities that you would like to purchase to our sales person, or email to us. 2. We will send you a Proforma Invoice to specify net cost of mentioned goods and other relevant charges once you confirm the order. 3. After you arrange the payment and send us your bank slip, we will put your order down to production, and let you know the ready date in 2 days. 4. When the goods are finished, we will send them by air express, or by sea, or other available shipping methods appointed by customers, and let you know the tracking number and estimated time of arrival. |
MOQ |
|
1. For the first order, we have no limit for the quantity. 2. From the second order, the MOQ is 50pcs. |
Payment Terms |
|
T/T, Western Union, PayPal 1. We can put customers' orders down to production once we get the bank slip copy. 2. If order value less than 20,000USD, we should get 100% payment before production; If order value more than 20,000USD, we accept 30% deposit before production and the balance should be paid off before delivery. |
Lead Time |
|
1. Sample order can be delivered from our factory in 7 working days. 2. General order can be delivered from our factory in 15 - 25 working days. 3. Big order can be delivered from our factory in 30-35 working days at most. |
OEM / ODM Service |
|
1. If the total order quantities are above 200pcs, we can silk-screen print customer’s logo on the products, and put customer’s model numbers in the labels, boxes, and in the manuals free of charge. 2. We accept ODM projects, and welcome your enquiries! |
Warranty Polic |
|
We provide two-year warranty for CCTV Cameras and DVRs after the shipment date. Any product proves defective under normal usage, we will repair or replace it by free of charge. 1. If our customers could repair the products by themselves locally, we will supply necessary spare parts. 2. If the customers couldn't repair the products, the products will need to be sent back to us, and we repair and bear 50% freight charge. All of our products are 100% passed strictly quality inspection before delivery. |
Technical Support |
We have professional technical support team to support our customers, and if you have any question for the technology of our products, please email to us, and we will reply to you immediately. Also if you have any doubt for the information on our website or any feedback for the quality of our products, please email to us, and thanks for your all comments in advance. |
