Low Carbon Compressor Tubes / Copper Coated Precise Tubes In Compressor 3.18 * 0.5 mm
1.materials: low carbon steel strip
2.main use: widely used in varity compressors
3.outer diameter: 3.18mm
4.wall thickness: 0.5mm
5. standard:YB/T4164-2007
6.certification:also passed ISO9001 quality attestation system and ISO14001 Certificate of Environment Management System
7.surface treatment: copper coated
8. Features:soft and easy to bend
9.tensile strength: more than 290 Mpa
10.yield strength:more than 180 Mpa
11.elongation:more than 25%
12. place of origin: changzhou city, jiangsu province, China
13. port of loading:shanghai, China
14. package:plastic cloth with coils, wooden boxes, iron pallets etc
15. delivery:as contract
16.payment terms:T/T,L/C etc
17. supply ability:25000 ton per year
18. brand:WUSHUN
Specifications:
specification |
Size tolerance |
Mechanical properties |
||||
Tolerance on O.D(mm) |
Wall thickness (mm) |
Tolerance on length(mm) |
Tensile strength |
Yielding point |
elongation |
|
precise tube in compressor 9.52*0.5mm |
±0.08 |
±0.08 |
≤±1 |
≥290Mpa |
≥180Mpa |
≥25% |
Competitive Advantage:
Double wall steel tube ,copper welding ,blast protection performance good,size is complete ,good quality according ASTM-254 .
