Coating Thickness Meter, NF Type CT-620NF
Description:
It meets the standards of both ISO2178 and ISO-2361 as well as DIN, ASTM and BS. Suitable for the laboratory and for use in harsh field conditions.
Application:
F type can measure the thickness of non-magnetic coating layers on magnetic substrate. Such as: (aluminum, chrome, copper, enamel, rubber, paint) on magnetic substrate (steel, iron, alloy and magnetic stainless steel).
NF type can measure the thickness of non-metal coatings layers covered on non-magnetic metals substrate. Such as: (enamel, rubber, paint, vanish, plastic anodic-oxide layer) covered on non-magnetic metals substrate (aluminum, brass, zinc and nonmagnetic stainless steel).
Features:
Small style design, conveniently carry
Complete intelligentized design, easily operate
Rapid measure, excellent repeated performance
Zero adjustment, manual calibration
LCD digital display
The metric system /England system unit transform
There is bee ring song prompt during operation
Automatic probe recognition
Manual or automatic shut down
Display:
μm indicate value unit (lμm=1/1000mm)
CAL ZERO Adjustment
Fe Magnetism substrate measure state
NFe Non-magnetism substrate measure state
Specification:
Operating Principle |
F:Magnetic Induction; NF: Eddy Current |
Measuring Range |
0~1250 um / 0~50 mil (other measuring range are optional) |
Resolution |
0.1 um / 1 um |
Min. Radius Workpiece |
F: convex 5 mm / concave 5 mm; NF Type: convex 5 mm / concave 5 mm |
Min. Measuring Area |
10*10mm |
Min. Sample Thickness |
0.4 mm |
Accuracy |
+/-1~3% or +/- 2 um |
Auto Power Off |
Yes |
Metric / Imperial |
Convertible |
Battery Indicator |
Low Battery Indicator |
Operating Conditions |
Temp. 0~40 °C, Humidity: 10~85 %RH |
Power Supply |
2 x 1.5 V AAA (UM-4) Battery |
Dimensions |
102 x 66 x 24 mm |
Weight |
99g (Including Batteries) |
Standard accessories:
1. Main Unit, 1pc
2. Probe (F Type / NF Type), 1pc of each
3. Calibration Base Set (F Type / NF Type), 1pc of each
4. Calibration Foils (50um, 100um, 250um, 500um), 1pc of each
5. Carrying Case, 1pc
6. Operation Manual, 1pc
