Home > Products > Electrical Meter > TM901N LAN Cable Tester
TM901N LAN Cable Tester
- 5000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Taiwan | Brand Name: | TENMARS | Model Number: | TM901N |
Product Description
TM901N/TM-902 LAN Cable Tester
Description:
- Detects opens, shorts, miswires and split pairs on the twisted pair cabling on the LAN cable.
- Measures length.
- Auto backlit.
- Auto power off.
Application:
The backlit LCD screen displays graph wire-map, opens, shorts, miswires, split pairs and the remote ID number all on one screen. Using multiple remote ID up to 8 locators to test on RJ-45 (UTP, STP) LAN cable.
Specification:
Model: | TM-901N | TM-902 (for OEM olny) |
Connector type | RJ-45 | |
Cable category | LAN cable (UTP, STP),cable. | |
Wire-map test | Detects opens, shorts, miswires, split pairs | |
Length test | up to 255 M (836 ft) | |
Length resolution | 0.1 m (ft) | |
Length units | Meter and Foot | |
Accuracy | +/- 10% + 1.0M (3 ft) | |
Operating temp. and RH | 5 to 40 °C, below 80% RH. | |
Storage temp. and RH | -10 to 60°C, below 70%. | |
Power | 9V batteryx1 | 1.5V battery x 6 |
Dimensions (L x W x H) | 130 x 56 x 38mm. | 156 x 73 x 35mm |
Weight | About 160g | About 170g |
Accessories
| User’s manual, battery, Carrying case, Test Cable x1, Remote ID (1) x1 |
