Help CenterDigital Insulation Resistance Meter, Datalogger, USB Interface, UT513A
Related Products
-
Digital Insulation Resistance Tester, Datalogger, USB Interface, UT513NegotiableMOQ: 1 Piece -
Handheld Insulation Resistance Tester, True RMS, Datalogger, UT505ANegotiableMOQ: 1 Piece
-
Handheld Insulation Resistance Tester, Multi-function, True RMS, Datalogger, UT505BNegotiableMOQ: 1 Piece
-
Digital Insulation Resistance Tester, Auto Range, UT501NegotiableMOQ: 1 Piece
-
Digital Portable Insulation Resistance Tester, Auto Range, UT502NegotiableMOQ: 1 Piece
Specification:
Specification |
Range |
Best Accuracy |
|
Model |
UT513A |
||
Insulation Resistance(Ω) |
Test Voltages |
500V/1000V/2500V/5000V |
0%~20% |
500V |
0.0MΩ~20GΩ |
±(3%+5) |
|
1000V |
0.0MΩ~40GΩ |
±(3%+5) |
|
2500V |
0.0MΩ~100GΩ |
±(3%+5) |
|
5000V |
0.0MΩ~1000GΩ |
±(3%+5) |
|
Short Circuit Current |
>3.0mA |
||
DC Voltage (V) |
600V |
±(2%+3) |
|
AC Voltage (V) |
600V |
±(2%+3) |
|
Features | |||
Auto Range |
Yes |
||
Auto Power Off |
Yes |
||
Secondary Display |
Yes |
||
Low Battery Indication |
Yes |
||
Data Logging |
18 |
||
Comparison |
Yes |
||
Polarization Index(PI) |
Yes |
||
Dielectric Absorption (DAR) |
Yes |
||
USB Interface |
Yes |
||
LCD Backlight |
Yes |
||
Analogue Bar Graph |
30 |
||
Over Range Warning |
Yes |
||
High Voltage Indication |
Yes |
||
Timer |
Around 15 minutes |
Yes |
|
General Characteristic | |||
Power |
1.5V Alkaline Batteries(LR14)×8 |
||
LCD Size |
123mm x 58mm |
||
Product Color |
Red & Grey |
||
Product Net Weight |
2Kg |
||
Product Size |
202mm×155mm×94mm |
||
Standard Accessories |
2PCs of one plug test lead to one alligator clip(Black and Green),1 PC of two plugs test lead to one alligator clip(Red), Batteries, Tool Box, USB Cable,PC Software CD, Power Adaptor |
||
Standard Individual Packing |
Gift Box, English Manual |
||
Standard Quantity Per Carton |
4 PCs |
||
Standard Carton Measurement |
525mm x 335mm x 345mm (0.061CBM Per Standard Carton) |
||
Standard Carton Cross Weight |
19Kg |
||
Contrast:
Specification |
Range |
Best Accuracy |
|||
Model |
UT511 |
UT512 |
UT513A |
||
Insulation Resistance(Ω) |
Test Voltages |
100V/250V/500V/1000V |
0%~20% |
||
500V/1000V/1500V/2500V |
0%~20% |
||||
500V/1000V/2500V/5000V |
0%~20% |
||||
100V |
0.1MΩ~500MΩ |
±(3%+5) |
|||
250V |
0.5MΩ~2GΩ |
±(3%+5) |
|||
500V |
1MΩ~4GΩ |
±(3%+5) |
|||
1MΩ~5GΩ |
±(3%+5) |
||||
0.0MΩ~20GΩ |
±(3%+5) |
||||
1000V |
2MΩ~10GΩ |
±(3%+5) |
±(3%+5) |
||
0.0MΩ~40GΩ |
±(3%+5) |
||||
1500V |
5MΩ~20GΩ |
±(3%+5) |
|||
2500V |
10MΩ~100GΩ |
±(3%+5) |
|||
0.0MΩ~100GΩ |
±(3%+5) |
||||
5000V |
0.0MΩ~1000GΩ |
±(3%+5) |
|||
Short Circuit Current |
<2mA |
<1.8mA |
>3.0mA |
||
DC Voltage (V) |
1000V |
±(2%+3) |
|||
600V |
±(2%+5) |
±(2%+3) |
|||
AC Voltage (V) |
750V |
±(2%+3) |
|||
600V |
±(2%+5) |
±(2%+3) |
|||
Low Resistance (Ω) |
0.1Ω~999.9Ω |
±(1%+3) |
|||
Features | |||||
Auto Range |
Yes |
Yes |
Yes |
||
Auto Power Off |
Yes |
Yes |
Yes |
||
Secondary Display |
Yes |
||||
Low Battery Indication |
Yes |
Yes |
Yes |
||
Data Logging |
18 |
18 |
18 |
||
Comparison |
Yes |
Yes |
Yes |
||
Polarization Index(PI) |
Yes |
Yes |
Yes |
||
Dielectric Absorption (DAR) |
Yes |
Yes |
Yes |
||
USB Interface |
Yes |
Yes |
|||
LCD Backlight |
Yes |
Yes |
Yes |
||
Analogue Bar Graph |
30 |
30 |
30 |
||
Over Range Warning |
Yes |
Yes |
Yes |
||
High Voltage Indication |
Yes |
Yes |
Yes |
||
Timer |
Around 30 minutes |
Yes |
|||
Around 15 minutes |
Yes |
Yes |
|||
General Characteristic | |||||
Power |
1.5V Alkaline Batteries(LR14)×8 |
||||
LCD Size |
123mm x 58mm |
||||
Product Color |
Red & Grey |
||||
Product Net Weight |
UT511-1.2Kg, UT512-1.8Kg, UT513A-2Kg |
||||
Product Size |
202mm×155mm×94mm |
||||
Standard Accessories |
UT511 - 2PCs of one plug test lead to one alligator clip(Black and Green), 1 PC of two plugs test lead to one alligator clip(Red), Batteries, Tool Box. |
||||
UT512/UT513A - 2PCs of one plug test lead to one alligator clip(Black and Green),1 PC of two plugs test lead to one alligator clip(Red), Batteries, Tool Box, USB Cable,PC Software CD, Power Adaptor | |||||
Standard Individual Packing |
Gift Box, English Manual |
||||
Standard Quantity Per Carton |
4 PCs |
||||
Standard Carton Measurement |
525mm x 335mm x 345mm (0.061CBM Per Standard Carton) |
||||
Standard Carton Cross Weight |
UT511-13Kg, UT512-18Kg, UT513A-19Kg |
||||
Optional Accessories* | |||||
Power Adaptor(UT511 only) | |||||
Accessories:
2PCs of one plug test lead to one alligator clip(Black and Green),1
PC of two plugs test lead to one alligator clip(Red),
Batteries,
Tool Box,
USB Cable,
PC Software CD,
Power Adaptor
