Specification:
Specifications | Range | Best Accuracy | |
Model | UT533 | ||
Insulation Resistance(Ω) | Test Voltage | 50V/100V/500V/1000V/2500V | 0%~10% |
50V | 0.1MΩ~50.0MΩ | ±(3%+5) | |
100V | 0.1MΩ~100.0MΩ | ±(3%+5) | |
250V | 0.2MΩ~99.9MΩ | ±(3%+5) | |
100MΩ~250MΩ | ±(3%+5) | ||
500V | 0.5MΩ~99.9MΩ | ±(3%+5) | |
100MΩ~500MΩ | ±(3%+5) | ||
1000V | 4.0MΩ~99.9MΩ | ±(3%+5) | |
100MΩ~999MΩ | ±(3%+5) | ||
1.00GΩ~2.00GΩ | ±(5%+5) | ||
Short-Circuit Current | <2mA | Yes | |
Multimeter Specifications | |||
DC Voltage (V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.09%+6) | |
AC Voltage(50Hz~1KHz) | 6V/60V/600V/1000V | ±(1%+3) | |
DC Current (A) | 60mA/600mA | ±(1.0%+2) | |
AC Current(50Hz~1KHz) | 60mA/600mA | ±(1.5%+2) | |
Resistance (Ω) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/40MΩ | ±(0.9%+2) | |
Capacitance (F) | 10nF/100nF/1μF/10μF/100μF | ±(3%+5) | |
Frequency (Hz) | 60Hz/600Hz/6KHz/60KHz/600KHz/1MHz | ±(0.1%+3) | |
Temperature (°C) | -40°C ~ 537°C | ±(1%+10) | |
Temperature (°F) | -40°F~998°F | ±(1%+18) | |
Features | |||
Display Count | 6000 | ||
Auto Range | Yes | ||
True RMS | Yes | ||
Diode | Yes | ||
Auto Power Off | Yes | ||
Continuity Buzzer | Yes | ||
Low Battery Indication | Yes | ||
Data Hold | Yes | ||
MAX/MIN | Yes | ||
Data Logging | 99 | ||
LCD Backlight | Yes | ||
Full Icon Display | Yes | ||
General Characteristic | |||
Power | 1.5V Alkaline Batteries(LR6)×6 | ||
LCD Size | 81mm * 46mm | ||
Product Color | Red and Grey | ||
Product Net Weight | 505g | ||
Product Size | 96.7mm * 202.8mm *46 mm | ||
Standard Accessories | Batterise, Test Lead, Alligator Clip, Point Contact Temperature Probe, Carrying Bag | ||
Standard Individual Packing | Gift Box,English Manual | ||
Standard Quantity Per Carton | 20 pcs | ||
Standard Carton Measurement | 460mm * 310mm * 368mm(0.053 CBM Per Standard Carton) | ||
Standard Carton Gross Weight | 12Kg | ||
Contrast:
Specifications | Range | Best Accuracy | |||
Model | UT531 | UT532 | UT533 | ||
Insulation Resistance(Ω) | Test Voltage | 500V/1000V | 0%~10% | ||
250V/500V/1000V | 0%~10% | ||||
50V/100V/500V/1000V/2500V | 0%~10% | ||||
50V | 0.1MΩ~50.0MΩ | ±(3%+5) | |||
100V | 0.1MΩ~100.0MΩ | ±(3%+5) | |||
250V | 0.2MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ||
100MΩ~250MΩ | ±(3%+5) | ±(3%+5) | |||
500V | 0.5MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
100MΩ~500MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | ||
1000V | 4.0MΩ~99.9MΩ | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
100MΩ~600MΩ | ±(3%+5) | ||||
100MΩ~999MΩ | ±(3%+5) | ±(3%+5) | |||
1.00GΩ~2.00GΩ | ±(5%+5) | ±(5%+5) | |||
Short-Circuit Current | <2mA | Yes | Yes | Yes | |
Multimeter Specifications | |||||
DC Voltage (V) | 60mV/600mV/6V/60V/600V/1000V | ±(0.09%+6) | ±(0.09%+6) | ±(0.09%+6) | |
AC Voltage(50Hz~1KHz) | 6V/60V/600V/1000V | ±(1%+3) | ±(1%+3) | ±(1%+3) | |
DC Current (A) | 60mA/600mA | ±(1.0%+2) | ±(1.0%+2) | ±(1.0%+2) | |
AC Current(50Hz~1KHz) | 60mA/600mA | ±(1.5%+2) | ±(1.5%+2) | ±(1.5%+2) | |
Resistance (Ω) | 600Ω/6KΩ/60KΩ/600KΩ/6MΩ/40MΩ | ±(0.9%+2) | ±(0.9%+2) | ±(0.9%+2) | |
Capacitance (F) | 10nF/100nF/1μF/10μF/100μF | ±(3%+5) | ±(3%+5) | ±(3%+5) | |
Frequency (Hz) | 60Hz/600Hz/6KHz/60KHz/600KHz/1MHz | ±(0.1%+3) | ±(0.1%+3) | ±(0.1%+3) | |
Temperature (°C) | -40°C ~ 537°C | ±(1%+10) | ±(1%+10) | ||
Temperature (°F) | -40°F~998°F | ±(1%+18) | ±(1%+18) | ||
Features | |||||
Display Count | 6000 | 6000 | 6000 | ||
Auto Range | Yes | Yes | Yes | ||
True RMS | Yes | Yes | Yes | ||
Diode | Yes | Yes | Yes | ||
Auto Power Off | Yes | Yes | Yes | ||
Continuity Buzzer | Yes | Yes | Yes | ||
Low Battery Indication | Yes | Yes | Yes | ||
Data Hold | Yes | Yes | Yes | ||
MAX/MIN | Yes | Yes | Yes | ||
Data Logging | 99 | 99 | 99 | ||
LCD Backlight | Yes | Yes | Yes | ||
Full Icon Display | Yes | Yes | Yes | ||
General Characteristic | |||||
Power | 1.5V Alkaline Batteries(LR6)×6 | ||||
LCD Size | 81mm * 46mm | ||||
Product Color | Red and Grey | ||||
Product Net Weight | 505g | ||||
Product Size | 96.7mm * 202.8mm *46 mm | ||||
Standard Accessories | UT531-Batterise, Test Lead, Alligator Clip, Carrying Bag | ||||
UT532/533-Batterise, Test Lead, Alligator Clip, Point Contact Temperature Probe, Carrying Bag | |||||
Standard Individual Packing | Gift Box,English Manual | ||||
Standard Quantity Per Carton | 20 pcs | ||||
Standard Carton Measurement | 460mm * 310mm * 368mm(0.053 CBM Per Standard Carton) | ||||
Standard Carton Gross Weight | 12Kg | ||||
Accessories:
Batterise,
Test Lead,
Alligator Clip,
Point Contact Temperature Probe,
Carrying Bag
