Help CenterCM-01 200A DC/AC Clamp Meter
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Taiwan, China
Brand Name:
TES
Model Number:
CM-01
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Power Clamp Meter True RMSNegotiableMOQ: 1 Piece -
Power Factor Power Clamp Meter True RMSNegotiableMOQ: 1 Piece
-
Power AC/DC Clamp Meter DataloggerNegotiableMOQ: 1 Piece
-
Power AC/DC Clamp Tester Datalogger RS232 SoftwareNegotiableMOQ: 1 Piece
-
Power Clamp Tester Power Clamp AnalyzerNegotiableMOQ: 1 Piece
Place of Origin
Taiwan, China
Brand Name
TES
Model Number
CM-01
Display Type
Digital Only
Measuring Current Range
200A
Measuring Voltage Range
0-400V
Measuring Resistance Range
0-400 W
CM-01 DC/AC Clamp Meter
Features
High Resolution DC/AC 10mA
23 mm Large Jaw Diameter
One Touch Zero for DCA adjustment
Specifications:
Range |
Resolution |
Accuracy |
Remarks |
DCA 0-40A |
10mA |
+/- 1.0% +/- 2dgts |
|
DCA 0-150A |
100mA |
+/- 1.0% +/-2 dgts |
|
DCA 150-200A |
100mA |
-2.2% +/- 2dgts |
|
ACA 0-40A |
10mA |
+/- 1.0% +/- 3 dgts |
|
ACA 0-150A |
100mA |
+/- 1.0% +/- 3 dgts |
|
ACA 150-200A |
100mA |
-2.2% +/- 3dgts |
|
DCV 0-400V |
0.1 V |
+/- 1.0% +/- 2dgts |
|
ACV 0-400V |
0.1 V |
+/- 1.0% +/- 2 dgts |
|
W 0-400 W |
0.1 W |
+/- 1.0% +/-2dgts |
beep if < 40 W (Approx.) |
Hz 0-1000KHz |
0.1-100 |
+/- 0.5% +/- 2dgts |
1V sensitivity Auto Range |
Power Source: 2 X 1.5V AA UM3 Batteries
Current Consumption: 10mA
Operating Condition: -10 °C to 50 °C at 85% max. RH
