1100 3003 5052 Aluminium Alloy Plate/coil
US$ 4 - 40
MOQ: 2 Tons
Key Specifications
Get Latest Price
Grade:
1000 Series
Temper:
Other, /
Type:
Coil
Payment & Shipping
Payment Methods:
Port of Shipment:
shunde
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Polyester Coating Wooden Aluminium CoilUS$ 4 - 16MOQ: 1000 Square Meters -
Aluminum Foil for Roller ShutterUS$ 4 - 40MOQ: 1000 Square Meters
-
Anodized Aluminum Sheet Aluminum Coating CoilUS$ 3,300 - 4,000MOQ: 2 Tons
-
Embossed Aluminum Coil 3003 5052US$ 3,500 - 4,000MOQ: 2 Tons
-
Color Coated Aluminum Coils Painted Using 20 YEARSUS$ 3,500 - 4,000MOQ: 2 Tons
Grade
1000 Series
Temper
Other, /
Type
Coil
Application
Roofing
Thickness
0.15-0.50MM
Width
1020-2020MM, 1020mm to 2020mm
Surface Treatment
Other, Coated, PE Coated, PVDF Coated
Alloy Or Not
Is Alloy
Place of Origin
Guangdong, China
Brand Name
ALCADEX
Model Number
1100
1100 3003 5052 aluminium alloy plate/coil
| ||
|
|
|
| Aluminum Alloy/Temper | AA1100/H16,AA3003/H18,AA3015/H18,AA5005/H24 |
| Thickness | 0.15mm-1.20mm |
| Width | 1020mm-2020mm;others on requested |
| Coil ID | 405MM/505MM |
| Single Weight | 2.5Tons/Roll or customized |
| Thickness of coating | PVDF coating:28-32um; PE coating:26-28um |
| Color | Solid/metallic color, wooden/marble pattern Or Customized |
| Paint | PPG / BECKERS |
| MOQ | 2Tons/Color/Size |
| Production ability | 1200Tons /monthly |
| Packing | Wrapping & Pallet |
| Application | Raw materials for ceiling,aluminium composite panel, aluminum sheet,aluminum signboards,advertisment board,display platforms,roofs,kitchen cabinet board |
| Delivery time | 15-60 day after getting deposit payment and color confirmation |
| Payment terms | T/T, L/C,Western Union/paypal |
| Chemical composition% | |||||||||
| Grade | Si | Fe | Cu | Mn | Mg | Cr | Ni | Zn | Al |
| 1050 | 0.250 | 0.400 | 0.050 | 0.050 | 0.050 | - | - | 0.050 | 99.50 |
| 1060 | 0.250 | 0.350 | 0.050 | 0.030 | 0.030 | - | - | 0.050 | 99.60 |
| 1070 | 0.200 | 0.250 | 0.040 | 0.030 | 0.030 | - | - | 0.040 | 99.70 |
| 1100 | Si+Fe:0.95 | 0.05-0.2 | 0.050 | - | - | 0.100 | - | 99.00 | |
| 1200 | Si+Fe:1.00 | 0.050 | 0.050 | - | - | 0.100 | 0.050 | 99.00 | |
| 1235 | Si+Fe:0.65 | 0.050 | 0.050 | 0.050 | - | 0.100 | 0.060 | 99.35 | |
| 3003 | 0.600 | 0.700 | 0.05-0.2 | 1.0-1.5 | - | - | - | 0.100 | remains |
| 3004 | 0.300 | 0.700 | 0.250 | 1.0-1.5 | 0.8-1.3 | - | - | 0.250 | remains |
| 3005 | 0.600 | 0.700 | 0.250 | 1.0-1.5 | 0.20-0.6 | 0.100 | - | 0.250 | remains |
| 3105 | 0.600 | 0.700 | 0.300 | 0.30-0.8 | 0.20-0.8 | 0.200 | - | 0.400 | remains |
| 3A21 | 0.600 | 0.700 | 0.200 | 1.0-1.6 | 0.050 | - | - | 0.10 | remains |
| 5005 | 0.300 | 0.700 | 0.200 | 0.200 | 0.50-1.1 | 0.100 | - | 0.250 | remains |
| 5052 | 0.250 | 0.400 | 0.100 | 0.100 | 2.2-2.8 | 0.15-0.35 | - | 0.100 | remains |
| 5083 | 0.400 | 0.400 | 0.100 | 0.40-1.0 | 4.0-4.9 | 0.05-0.25 | - | 0.250 | remains |
| 5154 | 0.250 | 0.400 | 0.100 | 0.100 | 3.1-3.9 | 0.15-0.35 | - | 0.200 | remains |
| 5182 | 0.200 | 0.350 | 0.150 | 0.20-0.50 | 4.0-5.0 | 0.100 | - | 0.250 | remains |
| 5251 | 0.400 | 0.500 | 0.150 | 0.1-0.5 | 1.7-2.4 | 0.150 | - | 0.150 | remains |
| 5754 | 0.400 | 0.400 | 0.100 | 0.500 | 2.6-3.6 | 0.300 | - | 0.200 | remains |
| 6061 | 0.40-0.8 | 0.700 | 0.15-0.40 | 0.150 | 0.8-1.2 | 0.04-0.35 | - | 0.250 | remains |
| 6063 | 0.20-0.6 | 0.350 | 0.100 | 0.100 | 0.45 | 0.100 | - | 0.100 | remains |
| 6082 | 0.7-1.3 | 0.500 | 0.100 | 0.40-1.0 | 0.6-1.2 | 0.250 | - | 0.200 | remains |
| 6A02 | 0.50-1.2 | 0.500 | 0.20-0.6 | Or Cr0.15-0.35 | 0.45-0.9 | - | - | 0.200 | remains |
| 8011 | 0.50-0.9 | 0.6-1.0 | 0.100 | 0.200 | 0.050 | 0.050 | - | 0.100 | remains |
a.Light weight
b.Low cost
c.Easier and convenient to install
d.Environmental friendly and energy saving
e.Anti-dirt and self-cleaning
f.Corrosion resistant and moisture proof
g.Weathering resistance stronger than stone material and valid time longer
h.Excellent ductility, can be made into various shapes
a.Vivid patterns:. All patterns are made according to real materials to reach the texture of real wood and marble.
b.Various choices: More than 100kinds of lifelike wooden / marble patterns are available for reference. Customized sample pattern making also available.
c.Durable coating: Self-cleaning, strong weather resistance. Pollution resistant and waterproof. PE polyester coating is valid for 10 years while PVDF fluoro-carbon resin coating is valid for over 15 years.
