embossed aluminum coil 3003 5052

FOB Price

USD $3,500 - $4,000 / Ton

2 Tons(Min.Order)

Supply Ability 25000 Square Meter / Square Meters per Month
Port shunde
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Guangdong, China	Brand Name:	alcadex	Model Number:	1050/1060/1100/3003/5052
Application:	ACP	Thickness:	0.15mm-3.0mm	Width:	1020-2020mm, 1020mm to 2020mm
Alloy Or Not:	Is Alloy	Grade:	5000 Series
Temper:	Other, /

Packaging Details

wrapping & pallet

Product Description

embossed aluminum coil 3003 5052

Aluminum Alloy/Temper	AA1100/H16,AA3003/H18,AA3015/H18,AA5005/H24
Thickness	0.15mm-1.20mm
Width	1020mm-2020mm;others on requested
Coil ID	405MM/505MM
Single Weight	2.5Tons/Roll or customized
Thickness of coating	PVDF coating:28-32um; PE coating:26-28um
Color	Solid/metallic color, wooden/marble pattern Or Customized
Paint	PPG / BECKERS
MOQ	2Tons/Color/Size
Production ability	1200Tons /monthly
Packing	Wrapping & Pallet
Application	Raw materials for ceiling,aluminium composite panel, aluminum sheet,aluminum signboards,advertisment board,display platforms,roofs,kitchen cabinet board
Delivery time	15-60 day after getting deposit payment and color confirmation
Payment terms	T/T, L/C,Western Union/paypal

Chemical composition%
Grade	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Al
1050	0.250	0.400	0.050	0.050	0.050	-	-	0.050	99.50
1060	0.250	0.350	0.050	0.030	0.030	-	-	0.050	99.60
1070	0.200	0.250	0.040	0.030	0.030	-	-	0.040	99.70
1100	Si+Fe:0.95		0.05-0.2	0.050	-	-	0.100	-	99.00
1200	Si+Fe:1.00		0.050	0.050	-	-	0.100	0.050	99.00
1235	Si+Fe:0.65		0.050	0.050	0.050	-	0.100	0.060	99.35
3003	0.600	0.700	0.05-0.2	1.0-1.5	-	-	-	0.100	remains
3004	0.300	0.700	0.250	1.0-1.5	0.8-1.3	-	-	0.250	remains
3005	0.600	0.700	0.250	1.0-1.5	0.20-0.6	0.100	-	0.250	remains
3105	0.600	0.700	0.300	0.30-0.8	0.20-0.8	0.200	-	0.400	remains
3A21	0.600	0.700	0.200	1.0-1.6	0.050	-	-	0.10	remains
5005	0.300	0.700	0.200	0.200	0.50-1.1	0.100	-	0.250	remains
5052	0.250	0.400	0.100	0.100	2.2-2.8	0.15-0.35	-	0.100	remains
5083	0.400	0.400	0.100	0.40-1.0	4.0-4.9	0.05-0.25	-	0.250	remains
5154	0.250	0.400	0.100	0.100	3.1-3.9	0.15-0.35	-	0.200	remains
5182	0.200	0.350	0.150	0.20-0.50	4.0-5.0	0.100	-	0.250	remains
5251	0.400	0.500	0.150	0.1-0.5	1.7-2.4	0.150	-	0.150	remains
5754	0.400	0.400	0.100	0.500	2.6-3.6	0.300	-	0.200	remains
6061	0.40-0.8	0.700	0.15-0.40	0.150	0.8-1.2	0.04-0.35	-	0.250	remains
6063	0.20-0.6	0.350	0.100	0.100	0.45	0.100	-	0.100	remains
6082	0.7-1.3	0.500	0.100	0.40-1.0	0.6-1.2	0.250	-	0.200	remains
6A02	0.50-1.2	0.500	0.20-0.6	Or Cr0.15-0.35	0.45-0.9	-	-	0.200	remains
8011	0.50-0.9	0.6-1.0	0.100	0.200	0.050	0.050	-	0.100	remains

a.Light weight

b.Low cost

c.Easier and convenient to install

d.Environmental friendly and energy saving

e.Anti-dirt and self-cleaning

f.Corrosion resistant and moisture proof

g.Weathering resistance stronger than stone material and valid time longer

h.Excellent ductility, can be made into various shapes

a.Vivid patterns:. All patterns are made according to real materials to reach the texture of real wood and marble.

b.Various choices: More than 100kinds of lifelike wooden / marble patterns are available for reference. Customized sample pattern making also available.

c.Durable coating: Self-cleaning, strong weather resistance. Pollution resistant and waterproof. PE polyester coating is valid for 10 years while PVDF fluoro-carbon resin coating is valid for over 15 years.
