Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Wire > Hot Dipped Galv. Low Carbon Steel Wire

Hot Dipped Galv. Low Carbon Steel Wire

Name: Hot Dipped Galv. Low Carbon Steel Wire
Brand: Jiaxi
SKU: 131355147
Availability: InStock

Hot Dipped Galv. Low Carbon Steel Wire thumbnail-1

Hot Dipped Galv. Low Carbon Steel Wire photo-1

US$ 620 - 705 MOQ: 10 Tons

Key Specifications

Get Latest Price

Standard:

AISI, ASTM, DIN, EN, GB, JIS, Other, ASTM, AISI, ASTM, DIN, EN, GB, JIS, Q195,SAE1006,BP05, ASTM,A411,BS443,BS1442

Grade:

300 Series

Wire Gauge:

0.5MM-4.2mm

Contact Supplier Request Quote Chat Now

Tangshan Jiaxi Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard AISI, ASTM, DIN, EN, GB, JIS, Other, ASTM, AISI, ASTM, DIN, EN, GB, JIS, Q195,SAE1006,BP05, ASTM,A411,BS443,BS1442

Grade 300 Series

Wire Gauge 0.5MM-4.2mm

Application construction and building

Certification Other

C Content (%) 0.14-0.22

Si Content (%) 0.30

Place of Origin Hebei, China

Brand Name Jiaxi

Model Number 0.8mm,0.9mm,1.25mm,1.6mm,2.0mm,2.5mm,3.15mm

Specifications

wire dia:0.5MM-4.2mm
zinc coating:145-350m2
T/S:300-500Mpa/mm2
coil w.50-800kg/coi

Material: Q195, SAE1006, BP05

Standard: ASTM A411 BS443 (EN10244-1,EN10244-2) BS1442 (EN10257-1)

Specifications & Character:

wire dia.	tolerance	zinc	tensile	elongation	resistance
mm	+/-mm	g/m2	N/mm2	min%	Max.ohm/km
0.8/0.90	0.025	>155	340-500	10	216.92
1.21/1.25	0.035	>180	340-500	10	112.45
1.54/1.6	0.045	>195	340-500	10	68.64
1.95/2.0	0.050	>215	340-500	10	43.93
2.50/2.54	+0.00 , -0.06	>245	340-500	10	28.11
3.05/3.15	+0.00 , -0.08	>275	340-500	10	17.71

We can also produce other wire diameter with any zinc coating.

Packing: 25kg-800kg/Coil, or by Wooden pallet or Scroll packing. Outer with plastic film and weaving bag.

Features/Usage: This kind of wire is made by special technical,which makes it very soft; excellet electro resistance and best Elongation. it is best material to making Armouring Cable.

Chemical Composition

Type	Grade	Chemical Composition(&)
		C	Mn	Si	S	P
				≤
Q195	1	0.06-0.12	0.25-0.50	0.30	0.050	0.045

Type	Q235				Standard NO.			GB 700-88
Chemical Composition%	C	Mn	Si		S	P	Cr			Ni	Cu
	0.14-0.22	0.30-0.60	0.30		0.050	0.045	0.30			0.30	0.30
Shape	Ingot,blank,profile,bar,plate,tube,strip line
Specification	Tensile strength(Mpa)			Yield strength(Mpa)					Elongation rate(%)
	375-460			185-235					21-26 as varied sizes
