Help CenterLarge Flake Ice Machine on Board
Related Products
Specifications
1. Flake ice maker2. ice -thickness,dryness and no powder
3.Material: stainless steel ect.
4.Certifi:CE,ISO19001,ISO14001
Flake ice machine on-board application field
1.Ports and terminals ice factory
2.Fishing, offshore fishing vessel with ice and other places
3.Coastal island fresh seafood
4.Fishery and aquatic food processing
5.Shipping Logistics preservation
6.Island chemicals,concrete cooling project
7.Fresh preservation and cooling field application
Flake ice machine on-board conditions
1.Electrical require: Full electric system complying
With the general international standard
2.Standard condilion: Water inlet temp.16°C Amibenttemp. 25°C
3.Application condilion: Ambient temp.5°C~40°C water temp. 0.5°C~35°C
4.Special condition: Ambient temp.-30°C~60°C water temp.0°C~46°C
5.Ice thickness: 1.5~2.2mm
6.Refrigerant: R717,R22 ,R404A,R507A
Flake ice machine on-board feature
As a way to directly produce ice and operate on fish boats with seawater, ice-making for ship usage its over 30 years experience abroad already while at the stage of research and development domestic pesently. Domestic refrigeraijon equipment manufacturer are prevented from develoing in the field of ice they machines for ship use since they have to get over such difficulties as seawater erosion, shaking ships, long time of renewed sailing and adverse climatic environment. As a professional manufacturer, SNOWKEY have produced ice flakers of various types which conform to domestic ocean fishing ships on the basis of producing ice flakers for fresh water use and sea water use in light of international market demand, climatic conditions and differences marine region. Etc.
— It produced ice flakes with thickness of 2.5mm, dryness and no powder. Its ice temperature is approximately -10°C
—The material of ice flake is stainless steel and anti-corrosion aluminum alloy, its using life can reaches to approximately 18 years.
—Special interior ice scraping way and the patented ice blade allow the ice machine to make ice normally even when the boat is in hard conditions at 35 Deg. of waving.
—No person is needed to operate, the system adopts all-automatic control, no need regulary maintenance, labor cost is greatly saved.
—Safe and energy-saving, it can use its shipping power to put out ice in 3-5 minuts.The quality of its product has reached the worfd's level.
Flake ice machine on-board performance parameter
| Model | Capacity | Compressor power |
Reducer power | Circulating Pump power |
Seawater circulating pump power |
Refrigerant |
| SFM-8 | 700KG/24h | 5HP | 0.18KW | 0.09KW | 0.37KW | R717/R404/R507/R22 |
| SFM-10 | 1000KG/24h | 6HP | 0.18KW | 0.09KW | 0.37KW | R717/R404/R507/R22 |
| SFM-20 | 2000KG/24h | 12HP | 0.37KW | 0.09KW | 0.55KW | R717/R404/R507/R22 |
| SFM-30 | 3000KG/24h | 20HP | 0.37KW | 0.09KW | 0.55KW | R717/R404/R507/R22 |
| SFM-40 | 4000KG/24h | 30HP | 0.37KW | 0.12KW | 0.75KW | R717/R404/R507/R22 |
| SFM-50 | 5000KG/24h | 40HP | 0.55KW | 0.25KW | 0.75KW | R717/R404/R507/R22 |
| SFM-75 | 7500KG/24h | 50HP | 0.75KW | 0.25KW | 1.1KW | R717/R404/R507/R22 |
