SXQ3210A Tumble Belt Type Shot Blasting Machine
This machine is mainly comprised of blasting turbines, blasting chamber, bucket elevator, air wash type separator, dust removing system and electrical control etc. It applies to intensify and de-rust of large and small jobs in foundry and forging, heat treatment industries.
Model |
SXQ326 |
SXQ3210 |
SXQ3210A |
Productivity |
0.6~1.2t/h |
2.0~2.8t/h |
2.0~2.8t/h |
Max Loading Weight |
200kg |
600kg |
600kg |
Max Weight Per job |
10kg |
25kg |
25kg |
Diameter of end plates |
Φ600mm |
Φ1000mm |
Φ1000mm |
Volume of rotary drum |
0.11cbm |
0.3cbm |
0.3cbm |
Shot Blasting Volume |
120kg/min |
250kg/min |
250kg/min |
Air Volume |
2200cbm/h |
3500cbm/h |
3500cbm/h |
Total Power |
12.7kw |
23.6kw |
26kw |
Size of machine |
3681×1650×5800mm |
3430×2700×4540mm |
5800×4200×4524mm |
Remark:SXQ3210A is auto loading and unloading type tumble belt shot blasting machine
