Factory Large Fiberglass Side Mount Deep Bed Sand Filter for Swimming Pool Industrial Used
Factory large fiberglass Side mount deep bed Sand Filter for swimming pool industrial used
Features
| Highlight Features | |
| Max operating pressure | 36psi/2.5bar |
| Max temperature | 43℃(109 °F) |
| Maximun filtration velocity | 50m³/h |
| Union connection provided | Universal standard |
| Suggested size of media | 0.5-1.2mm |
| Dual layers of laterals | 1 pc |
| Sight glass | 4" |
| Manhole for servicing | 158mm |
| Bottom drain | 2" |
SDB SERIES Side mount Deep Bed filter offers a more thorough filtration with the standard of eight1.0m or 1.2m depth and bed which is suitable for high demand in filtration
performance of domestic swimming pool.
Functions
1. Designed for commercial purpose with long life and minimal servicing.
2. UV and corrosion resistance surface allow the filter to work under direct sunlight.
3. Automatic air release system enables easy release of trapped air during operation of the fiter.
4. Specially design and suitable for high demand in filtration surface area.
Technical characteristics
SDB Series Side mount deep bed sand filter
88013835 |
SDB700-1.0 |
28" Sand Filter, 1m Filtration Bed, 2" Multiport Valve |
15.2m³/h flowrate |
88013837 |
SDB800-1.0 |
32" Sand Filter, 1m Filtration Bed, 2" Multiport Valve |
20m³/h flowrate |
88013839 |
SDB900-1.0 |
36" Sand Filter, 1m Filtration Bed, 2" Multiport Valve |
25.2m³/h flowrate |
88013841 |
SDB1000-1.0 |
40" Sand Filter, 1m Filtration Bed, 2" Multiport Valve |
31.2m³/h flowrate |
88013836 |
SDB700-1.2 |
28" Sand Filter, 1.2m Filtration Bed, 2" Multiport Valve |
15.2m³/h flowrate |
88013838 |
SDB800-1.2 |
32" Sand Filter, 1.2m Filtration Bed, 2" Multiport Valve |
20.0m³/h flowrate |
88013840 |
SDB900-1.2 |
36" Sand Filter, 1.2m Filtration Bed, 2" Multiport Valve |
25.2m³/h flowrate |
88013842 |
SDB1000-1.2 |
40" Sand Filter, 1.2m Filtration Bed, 2" Multiport Valve |
31.2m³/h flowrate |
88013853 |
SDB900(C)-1.0 |
36" Sand Filter, 1m Filtration Bed, 2.5" Multiport Valve |
31.5m³/h flowrate |
88013854 |
SDB900(C)-1.2 |
36" Sand Filter, 1.2m Filtration Bed, 2.5" Multiport Valve |
31.5m³/h flowrate |
88013855 |
SDB1000(C)-1.0 |
40" Sand Filter, 1m Filtration Bed, 2.5" Multiport Valve |
39m³/h flowrate |
88013856 |
SDB1000(C)-1.2 |
40" Sand Filter, 1.2m Filtration Bed, 2.5" Multiport Valve |
39m³/h flowrate |
Payment Terms
1. Payment:30% in advance,+70% balance should be paid before delivery.
2. Lead time:1x20ft for 15 days;1x40ft for 20 days
3. Port of loading:guangzhou, China (Mainland)
4. Discounts are offered based on order quantities.
1. More than 15 years production & sales experience
2. Direct selling with guaranteed quality products
3. Good reputation,buyers choice
4. Warranty and good after-sale service.
5. Timely Delivery
6. Unbeatable price
7. Top Craftmanship
8. China's only company with complete range of swimming pool and spa products.
About Us
Our company, Guangzhou Vigor Health Equipment Co., Ltd is professional in spa, sauna, swimming pool equipment. We have been in this area for more than 15 years and our own factory is located in Qingyuan City. Welcome to visit our factory. We are sure to offer you a competitive price with the best quality in this market.
Welcome to visit our showroom and factory.
Our certificate and exihibition
With us,your money in safe,with us,you business in
safe,as quality is our culture.
Welcome to visit our showroom and factory!
Attn:Flora:sales5&
Skype:flora2008miumiu
WhatsApp/Viber/Wechat/Mobile:+0086 13928998560/13556025664
