ZCFZ-12 Air Cooling Refrigerating Type Industrial Dehumidifier
- Specially designed and used for Steel Coating etc.
1 Working Principle
1.1 Dehumidifying working principle
The humid air will first go through air filters for filtering then it will be via evaporator of cooling system. The wet air will fully touch with the surface of evaporator. Because the surface temperature of evaporator is lower than dew point temperature of humid air, the vapor will get cooled and condense to water drops. The water drop will be collected in stainless steel panel and discharged. Thus the temperature and humidity become lower. Then the air will be reheated. Thus we can get air with required temperature and humidity.
1.2 Auto control principle
To the character of this equipment, we adopt advanced PLC program control system to auto control temperature and humidity optimized automatically. It adopts PLC + Touch Screen control which can show operation, shut down, failures etc. The electrical control cabinet has functions of dust-proof, water-proof; The system has self-diagnosis and interlocked functions. It alarms and stops the equipment automatically when there are failures.
2 Introduce of equipment
2.1 Equipment characters
1) Compact structure, good outlook.
2) Low operation cost and energy saving. In refrigerating system, it has adjusting device (compressor 25%, 50%, 75% and 100%). This makes that it does not need preheating and the equipment can work well. It will save about 20% energy.
3) The regeneration heating will be controlled by the humidity of outlet air from evaporator. When the humidity meets the requirements, the regeneration heating power will be not increased. Also the regeneration heating power is by step control and it can control the humidity accurately. Compared with normal design, it will save about 15% energy.
4) Operation reliable. ISO9000 international quality management system, and choose spare parts by qualified supplier which has famous brand home and abroad which can guarantee reliability of equipment.
5) Easy operation. It adopts touch screen centralized control and fault display, recording. It makes the operation easy.
2.2 Composition of equipment
The equipment is comprised of refrigerating system (compressor, condenser, evaporator, throttle parts), reheating system, ventilation system ( high pressure centrifugal air blower, filtering net) and intelligent electrical control system.
It has maintenance ladder, steel structure main frame, main air ventilation ducting, ducting adopts sealant, insulating structure. Under evaporator, there is a stainless steel panel for collecting water and water drain pipe; For condenser fan, there is a protective net. Forklift channel and lifting eye.
Main composition of equipment as follows:
1) Filtering: it adopts non-woven fabric G4 filtering net which is of good filtering effectiveness, small wind resistance, easy dust clean.
2) Refrigerating machine: it adopts air cooling refrigerating machine, compressor from Italy Refcomp screw compressor, 4 step energy adjusting, protection of phase fault, phase sequence, oil level and so on.
3) Reheater adopts stainless steel fin electrical resistance, controlled by PLC and multilevel control.
4) Electrical control system: it adopts advanced PLC + Touch screen + Sensor. The client only needs to input the air outlet humidity, the equipment will run according to settled requirements automatically. At the same time, the touch screen can show working situation, faults and temperature & humidity of air outlet.
5) The electrical elements adopts Siemens/Schneider brand, sensor adopts imported elements, reliable. The design is easy for operation and maintenance.
3 Main technical parameters
Equipment Model |
ZCFZ-12 |
Electrical power |
380V/50Hz/3Ph |
Main control procedure |
PLC auto control + Manual Operation |
Dehumidifying air volume |
12000m3/h |
Extra pressure of exhaust air |
≥2000 Pa |
Compressor |
Italy Refcomp screw compressor |
Condenser cooling type |
Air cooling |
Refrigerant |
R22 (update available) |
Heating type |
Stainless electrical heater heating |
Temperature control type |
High sensitive temperature sensor +PLC auto control +Touch Screen Display |
Air inlet condition |
Temperature 20~32°C, Humidity: RH≤75%~95% |
Air outlet condition |
Temperature≥25±3°C, Humidity RH≤45% |
Cooling capacity unloading |
4 stage (25%~50%~75%~100%) auto unloading |
Dew point |
5~13°C |
Evaporator |
Copper tube + hydrophilic copper fins |
Condenser |
Copper tube + aluminum fins |
Structure of equipment |
Container structure as one whole |
Size of air outlet |
4×Φ250mm round outlet with switch valve and connection joint |
Electrical control cabinet |
PLC control IP54 sealant + protection of electrical linkage, phase default, high and low voltage, overload + air pressure exceeding protection Protection for electric and pneumatic separately Self-diagnosis 415V/50Hz/3Ph |
Temperature & humidity control and display |
4 stage auto unload cooling + 4 stage auto temperature adjusting electrical heating; temperature outlet display |
Fault display |
Phase sequence protection / compressor fault / overload display / air pressure exceeding / no air flow in ducting alarming / overheating of electrical heater alarming etc. |
|
Pressure display & protection |
High, low pressure display + Protection |
Air inlet filtering |
Efficiency 93% / Washable double layer filtering / frame material aluminum alloy / filtering precision 0.5μm |
Weight |
≤5 tons |
Max outsize |
L×W×H: 3600mm×2200mm×2500mm |
Premier paint & film thickness |
2×100μm Paint: epoxy Color: Ocean blue |
Finish paint & film thickness |
2×75μm Paint: epoxy Color: Ocean blue |
