Home > Instruments & Meters > Test Instrument > Test Machine > DIL-201 Automatic Distillation Range Apparatus for Oil, Petroleum Products Distillation Range Tester

DIL-201 Automatic Distillation Range Apparatus for Oil, Petroleum Products Distillation Range Tester

DIL-201 Automatic Distillation Range Apparatus for Oil, Petroleum Products Distillation Range Tester photo-1
US$ 2,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Chongqing, China
Brand Name:
Top
Model Number:
DIL-201
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Chongqing, China
Brand Name Top
Model Number DIL-201
Product Description


DIL-201 automatic distillation range apparatus for oil, petroleum products distillation range tester




Applications:


DIL-201 oil distillation tester is suitable for distillate determination for natural gasoline(stable light hydrocarbon), motor gasoline, aviation gasoline, jet fuel, special boiling point solvent, naphtha, petroleum solvent oil, kerosene, diesel, crude oil, distillate fuels and similar petroleum products.
The instrument is designed and manufactured in accordance with the national standard GB/T 6536, GB/T 7534, GB/T 2282, GB/T 18255,ASTM D86 ASTM D850 ISO 3405. It adopts the original temperature sensor of German JUMO company and the most advanced CNC optical detection system. It can automatically complete the whole process of distillation testing. It is dual ways structure and can simultaneously test two samples.With reasonable structure, stable performance and simple operation, it is an ideal analysis equipment.


Technical Parameter:

Temperature range
room temperature~400℃; resolution 0.10.1℃.
Water bath uniform temperature range:
0~60℃ (compressor refrigeration) ; internal circulation.
Recovery chamber thermostat range
3~40℃.
Distilling rate
4~5ml/min
 Volume detection range
0~101ml; resolution 0.1ml
Temperature testing components:
PT100 (original temperature sensors of German JUMO company).
Display
128*64 large-screen display in English.
Heating method
infrared radiated heating
Printing
20 lines character dot matrix printing
Power consumption
 less than 4kw
Refrigeration
refrigerated by compressor (France DANFOS)
Ambient temperature
15~35℃
Humidity
30%~80%RH
Power supply
220±10%V AC 50Hz±2Hz
Operation mode
program start; simple operation (domestic exclusive technology).
Our Company


Chongqing TOP Oil Purifier Co.,Ltd is a leading professional manufacture of oil purifiers and oil testers from China. We practiced in this line for more than 20 years and has grown to be a full skilled team in tech research, operating,  producing with rich experience.We work out oil solution projects aiming at customers’ oil problems and needs.

We strongly cared our products are in good function,high efficiency, great cost performance, security,and ecological attention with environmental protection.

Our products help you:
• save oil change cost
• solve oil disposal problem
• keep equipment working more efficiently
• protect machinery and reduce maintenance time
• create a cleaner environment

Our factory

Our Certificate

Our Service

Pre-Sales Service

* Professional pre-sale model/configuration selection advise and technical support -- offered by experienced technician.

* Free on-site installation, debugging and technical training -- offered by strictly trained technology application engineers.

After-Sales Service

* The warranty period is 24 months from commissioning acceptance date on. After the warranty period is over we provide lifelong maintenance and technical service.

* We guarantee the maintenance time no more than 3 working days and response time within 1 hour.

* We build instrument service profile for our clients to record the product service and maintenance conditions

* After instruments start service, we will pay follow-ups to collect the service conditions

Packing & Delivery
Contact Us










keywords: petroleum products distillation range tester,distillation analyzer,oil product distillation tester,distillation range of petroleum products,distillation range apparatus for oil,distillation apparatus
