Single Beam Low Headroom Wire Rope Hoist

Single Beam Low Headroom Wire Rope Hoist thumbnail-1
Single Beam Low Headroom Wire Rope Hoist photo-1
US$ 3,500 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
LIFTKING
Contact Supplier Request Quote Chat Now
More-Safe Enterprises
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name LIFTKING
Model Number MSF-EWRHL
Usage Construction Hoist
Power Source Electric
Sling Type Wire Rope
Maximum Lifting Weight 25t
Maximum Lifting Height 18m
Lift Speed 5/0.8m/min
Certification CE
Warranty 12months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

single beam low headroom wire rope hoist
1.brand LIFTKING
2.capacity 2t - 20t
3.lifting height : 6 9 12 15 18m

Specifications



pact structure
2.lightweight/small volume
nvenient operation
4.European style

single beam low headroom wire rope hoist







Including: single girder electric hoist



MSF series Electric wire rope hoist is a newly developed electric hoist by our company on the basis of introducing advanced German manufacturing technology of electric wire rope hoist integrating the up to date standard of Hoist. It has rectangular shape with the electromotor, planetary reducer and electric in beeline collocation. Reducer is laid inside the hoisting drum, which can completely compare beauty with the same kind of products of foreign countries whether in the appearance or in the technique feature. Especially the modular design reveals the seamless connection with frequency inverter controlled automatic running of high or low speed diving or lifting.





Type Single Girder Low Headroom
Capacity (t) 2000 3200 5000 8000
Lifting Height (m) 6 9 12 15 18 6 9 12 15 18 6 9 12 15 18 6 9 12 15 18
Lifting Speed (m/min) 5/0.8 5/0.8 5/0.8 5/0.8
Lifting Motor (kw) 3.2/0.45 3.2/0.45 6.1/1 9.5/1.5
Traveling Speed (m/min) 5/20 5/20 5/20 5/20
Traveling Motor (kw) 0.37 0.37 0.37 0.75
Wire Rope Breaking Force 2160N/mm^2
Safety factor  4.5:1
Insulation Grade F
Control Panel IP65
Working Grade
(FEM/ISO)		 Lifting 3M / M6 2M / M5 2M / M5 3M / M6
Traveling 2M /M5 2M /M5 2M /M5 2M /M5
Dimension
(mm)		 H 210 210 260 325
C 556 556 596 750
B 150-300 150-300 200-350 200-410

Type Single Girder Low Headroom
Capacity (t) 10000 12500 16000 20000
Lifting Height (m) 6 9 12 15 18 6 9 12 15 18 6 9 12 15 18 6 9 12 15 18
Lifting Speed (m/min) 5/0.8 4/0.6 4/0.6 4/0.6
Lifting Motor (kw) 9.5/1.5 12.5/2 16/2.6 16/2.6
Traveling Speed (m/min) 5/20 5/20 5/20 5/20
Traveling Motor (kw) 0.75 0.75 0.75*2 0.75*2
Wire Rope Breaking Force 2160N/mm^2
Safety factor  4.5:1
Insulation Grade F
Control Panel IP65
Working Grade
(FEM/ISO)		 Lifting 2M / M5 1Am / M4 2M / M5 1Am / M4
Traveling 2M / M5 2M / M5 2M / M5 2M / M5
Dimension
(mm)		 H 325 325 400 400
C 750 750 920 920
B 200-410 200-410 300-450 350-400
