72W SMD3014 LED Panel Light

Name: 72W SMD3014 LED Panel Light
Brand: Colin
SKU: 131220263

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Color Temperature(CCT):

Warm White

Lamp Body Material:

Aluminum

Place of Origin:

Guangdong, China

Shenzhen Colin LED Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Color Temperature(CCT) Warm White

Lamp Body Material Aluminum

Place of Origin Guangdong, China

Brand Name Colin

Model Number CL-PL-600X600-72W

Specifications

our products used the lumenmax SMD3014 LED ,the thickness can reach 9mm,the luminous can reach 5040Lm

Specification
Model	CL-PL-600X1200-60W
Lighting source	Lumenmax SMD3014 LED
LED QTY	720pcs
Power consumption	72W(includes driver)
Input voltage (Driver)	90-135VAC or 175-265VAC /50-60HZ
Input voltage (Lighting)	72~84VDC
Constant current	900mA
Efficiency	≥85%
PF	≥0.90
LED Lifespan	≥ 50000H
CCT	3500K
Luminous	5040Lm±5%
Luminescence efficiency	70 lm/w
Bean-angle	120 °
Ra	Ra ≥ 75
Temperature rising	< 20 °C
Operation temperature	-40~+50°C
Relative humidity	10%-80%RH
Fixture Material	Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser
Dimension	595 x 1195 x 9.0mm
Net Weight (includes driver)	7.2KG
Protection grade	IP44
Insulation class	CLASS II
Environmental	All materials meet with RoHS compliance
Certificate	CE, RoHS
