Home > Lights & Lighting > LED Interior Lighting > LED Panel Light > 24W High Brightness Build Led Light Panel

24W High Brightness Build Led Light Panel

Name: 24W High Brightness Build Led Light Panel
Brand: Colin
SKU: 131219787
Availability: InStock

US$ 38 - 40 MOQ: 100 Pieces

Key Specifications

LED Light Source:

Lumenmax SMD3014 LED

Warranty(Years):

Input Voltage(V):

85~265VAC/50-60Hz

Shenzhen Colin LED Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source Lumenmax SMD3014 LED

Warranty(Years) 3

Input Voltage(V) 85~265VAC/50-60Hz

Lamp Power(W) 24

Lamp Luminous Flux(lm) 1680

Lamp Luminous Efficiency(lm/w) 70

Color Temperature(CCT) Cool White

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 50000

Lamp Body Material Aluminum Alloy

IP Rating IP44

Certification CE, FCC

Place of Origin Guangdong, China

Brand Name Colin

Model Number CL-PL-300X300-24W

Specifications

led panel light
1)Pretty design led panel
2)SMD3014 led panel lighting
3) 3 year warranty LED panel
4)led panel light..

Specification
Model	CL-PL-300X300A-24W
Lighting source	Lumenmax SMD3014 LED
LED QTY	240pcs
Power consumption	24W(includes driver)
Input voltage (Driver)	90-135VAC or 175-265VAC /50-60HZ
Input voltage (Lighting)	24~28VDC
Constant current	900mA
Efficiency	≥85%
PF	≥0.90
LED Lifespan	≥ 50000H
CCT	6500K
Luminous	1680Lm±5%
Luminescence efficiency	70 lm/w
Bean-angle	120 °
Ra	Ra ≥ 75
Temperature rising	< 20 °C
Operation temperature	-40~+50°C
Relative humidity	10%-80%RH
Fixture Material	Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser
Dimension	295 x 295 x 9.0mm
Net Weight (includes driver)	1.0KG
Protection grade	IP44
Insulation class	CLASS II
Environmental	All materials meet with RoHS compliance
Certificate	CE, RoHS
