Led Panel Price

Name: Led Panel Price
Brand: Colin
SKU: 131220187
Availability: InStock

US$ 78 - 84 MOQ: 20 Pieces

Key Specifications

LED Light Source:

lumenmax SMD3014 LED

Warranty(Years):

Input Voltage(V):

85~265VAC

Shenzhen Colin LED Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source lumenmax SMD3014 LED

Warranty(Years) 3

Input Voltage(V) 85~265VAC

Lamp Power(W) 30

Lamp Luminous Flux(lm) 2100

Lamp Luminous Efficiency(lm/w) 70

Color Temperature(CCT) Warm White

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 30000

Lamp Body Material Aluminum

IP Rating IP55

Certification CE, FCC

Place of Origin Guangdong, China

Brand Name Colin

Model Number CL-PL-1200X300-30W

Specifications

our products used the lumenmax SMD3014 LED ,
the thickness can reach 9mm,
the luminous can reach 2100Lm

Specification
Model	CL-PL-300X1200-30W
Lighting source	Lumenmax SMD3014 LED
LED QTY	300pcs
Power consumption	30W(includes driver)
Input voltage (Driver)	85~265VAC /50-60HZ
Input voltage (Lighting)	30~35VDC
Constant current	900mA
Efficiency	≥85%
PF	≥0.90
LED Lifespan	≥ 50000H
CCT	3500K
Luminous	2100Lm±5%
Luminescence efficiency	70 lm/w
Bean-angle	120 °
Ra	Ra ≥ 75
Temperature rising	< 20 °C
Operation temperature	-40~+50°C
Relative humidity	10%-80%RH
Fixture Material	Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser
Dimension	1195 x 295 x 9.0mm
Net Weight (includes driver)	3.6KG
Protection grade	IP44
Insulation class	CLASS II
Environmental	All materials meet with RoHS compliance
Certificate	CE, RoHS
