High Power 600x600 LED Panel Light

Name: High Power 600x600 LED Panel Light
Brand: Colin
SKU: 131220115

US$ 30 - 60 MOQ: 100 Pieces

Key Specifications

LED Light Source:

SMD3014

Warranty(Years):

Input Voltage(V):

100-240VAC

Shenzhen Colin LED Lighting Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

LED Light Source SMD3014

Warranty(Years) 3

Input Voltage(V) 100-240VAC

Lamp Power(W) 60

Lamp Luminous Flux(lm) 4200

Lamp Luminous Efficiency(lm/w) 75

Color Temperature(CCT) Cool White

Working Temperature(℃) -40, 50

Working Lifetime(Hour) 30000

Lamp Body Material Aluminum

Certification CE

Place of Origin Guangdong, China

Brand Name Colin

Model Number CL-PL-600X600-60W

Specifications

1)our products used the lumenmax SMD3014 LED
2)the thickness can reach 9mm
3)the luminous can reach 3360Lm

Specification
Model	CL-PL-600X600-60W
Lighting source	Lumenmax SMD3014 LED
LED QTY	600pcs
Power consumption	60W(includes driver)
Input voltage (Driver)	90-135VAC or 175-265VAC /50-60HZ
Input voltage (Lighting)	48~70VDC
Constant current	1050mA
Efficiency	≥85%
PF	≥0.90
LED Lifespan	≥ 50000H
CCT	6500K
Luminous	4200Lm±5%
Luminescence efficiency	70 lm/w
Bean-angle	120 °
Ra	Ra ≥ 75
Temperature rising	< 20 °C
Operation temperature	-40~+50°C
Relative humidity	10%-80%RH
Fixture Material	Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser
Dimension	595 x 595 x 9.0mm
Net Weight (includes driver)	4.2KG
Protection grade	IP44
Insulation class	CLASS II
Environmental	All materials meet with RoHS compliance
Certificate	CE, RoHS
