Home > Products > LED Panel Light > High brightness ultra-thin 600x600 LED panel lighting with 3warranty

High brightness ultra-thin 600x600 LED panel lighting with 3warranty

FOB Price

USD $30 - $50 / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

LED Light Source	SMD3014	Warranty(Years)	3
Input Voltage(V)	100-240	Lamp Power(W)	24
Lamp Luminous Flux(lm)	1680Lm	Lamp Luminous Efficiency(lm/w)	80
Color Temperature(CCT)	Warm White	Working Temperature(℃)	-20, 50
Working Lifetime(Hour)	30000	Lamp Body Material	Aluminum
IP Rating	IP65	Certification	CE
Place of Origin	Guangdong, China	Brand Name	Colin
Model Number	CL-PL-600X600-24W

1)our products used the lumenmax SMD3014 LED ,
2)the thickness can reach 9mm,
3) luminous can reach 1680Lm

Specification
Model	CL-PL-600X600-24W
Lighting source	Lumenmax SMD3014 LED
LED QTY	240pcs
Power consumption	240W(includes driver)
Input voltage (Driver)	90-135VAC or 175-265VAC /50-60HZ
Input voltage (Lighting)	24~28VDC
Constant current	900mA
Efficiency	≥85%
PF	≥0.90
LED Lifespan	≥ 50000H
CCT	3500K
Luminous	1680Lm±5%
Luminescence efficiency	70 lm/w
Bean-angle	120 °
Ra	Ra ≥ 75
Temperature rising	< 20 °C
Operation temperature	-40~+50°C
Relative humidity	10%-80%RH
Fixture Material	Oxidized Aluminum + High Quality PMMA (Acrylic)+PC diffuser
Dimension	595 x 595 x 9.0mm
Net Weight (includes driver)	1.0KG
Protection grade	IP44
Insulation class	CLASS II
Environmental	All materials meet with RoHS compliance
Certificate	CE, RoHS

Dimension
