MSR Card Reader Writer MSR609 Comp Msr206 Msr605 Msr606

MSR Card Reader Writer MSR609 Comp Msr206 Msr605 Msr606 photo-1
MSR Card Reader Writer MSR609 Comp Msr206 Msr605 Msr606 photo-2
MSR Card Reader Writer MSR609 Comp Msr206 Msr605 Msr606 photo-3
US$ 150 - 180 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
MSR
Model Number:
609, MSR609
Type:
CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Brand Name MSR
Model Number 609, MSR609
Type CF Card, Memory Stick Card, MMC Card, SD Card, SM Card, XD Card
Card Slots All in 1 / Multi in 1
Installation External
Place of Origin Guangdong, China

MSR609 High-speed USB Magnetic Strip Card Reader Writer

Plug and play, not need usb driver,easy to use Compatible MSR206



Package including

 * MSR609 + * Software+ * Power adaptor +* USB cable  directly

  * 1 clear Card * 1 Test Magnetic Card

- CE, FCC, UL, cUL,ROHS certified

- One year warrenty



Why choose MSR609?



Answer 1: MSR609 is the easiest encoder in the world!

MSR609 coming with direct USB cable, plug and play,not need install USB driver ,easy to use, All the people are experts.



Answer 2: MSR609 is the fast encoder in the world!

MSR609 have a truly Highspeed USB interface,fast computer communications,not the USB emulation serial writers in the market.



Answer 3: MSR609 is the compatible encoder in the world!

MSR609 can working with mini readers directly with our free software,you can easy transfer card data to pc and write to new cards quickly with MSR609.



Answer 4: MSR609 is the strongest encoder in the world!

MSR609 coming with Free software, Easy read,write cards.

Read and Write High & Low Coercive force of magnetic stripe (300~4000Oe)

All 3 tracks can set to 75 or 210 BPI

Sequential write function, partial or full track data(0~104 digits).

Windows 98/me/2000/xp/vista/windows 7(32&64 bit) ok!



Product Information

Features
- Reading/Writing magnetic stripe card complied with ISO formats
- Program software for Windows XP/Vista 32 or 64 bit systems
- Programming software for various read/write performance
- Sequential write function, partial or full track data(0~104 digits)

- All 3 tracks can set to 75/210 BPI
- Manual Swipe to read and/or write card with USB output
- Writing and verifying data on single, dual, or triple track in one swipe
- Comes with high-speed USB connection to computer and laptops without USB driver
- Read and Write High & Low Coercive force of magnetic stripe (300~4000Oe)
- High/Low Coercivity encoding circuitry selectable on screen
- Programmable leading bit, raw data, DMV/AAMVA, and user defined format

- Works with DOS/Linux and Windows 95/98/Me/2000/NT/XP/VISTA/Windows 7

- DC+24V, 2.5A Max external power adapter attached
- dimensions of 212(L) x 64(W) x 63(H) mm

- Warranty: One year warrenty



Electrical


Power requirements

 +24VDC +/- 5%

Consumption

Typical 350mA Max.  600mA plus for each writing track

Power supply

External switching power 24V/2.5A

Communication

HID USB

Ripple

50mVp-p or less

Dielectric strength

500 VDC for 1 minute

Performance


Read card

 Track1   Track2   Track3

Bit per density

210 bpi   75/210bpi   210 bpi

Coercive force

 Read/write 300-4000 oe Mag.card

Card thickness          0.76-1.2mm

Read speed

STD card    Jitter +/-15%   Amp. 60%

5-55ips    5-50ips            5-50ips

Write speed

 5-30ips

Write jitter

Interval < +/- 10%, Sub-interval < +/- 12%

Error rate

Read < 0.5%  Write < 0.8%

Head life

Min. 1000K swipes for both read/write head

Rate:



CE, FCC, UL, CUL, RoHS certified



The pictures of  magnetic card reader writer msr609

MSR card reader writer MSR609 Comp msr206 msr605 msr606MSR card reader writer MSR609 Comp msr206 msr605 msr606MSR card reader writer MSR609 Comp msr206 msr605 msr606
