4 Gallon Plastic Bottle/toolbox Blow Molding Machine
- FOB SHANGHAI
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PE | Blow Moulding Type | Extrusion Blow Moulding | |
| Automatic | Yes | Place of Origin | Jiangsu, China | |
| Brand Name | APOLLO | Model Number | ABLB90II | |
| Voltage | 220V/380V | Power(W) | 39KW | |
| Dimension(L*W*H) | 4.2X3X3.2M | Weight | 11T | |
| Certification | CE | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
blow molding machine1,CE Certification
2,Advanced technology
3,Good after-sale service
4,Competitive price
ABLB90II full automatic plastic bottle blow molding machine
ABLB90Ⅱ4 gallon bottle blow molding machine was specially designed for making plastic water gallons, lubricant oil bottles, tool boxes, plastic drums, and other plastic containers not over 20L.
The features of this machine:
(1)It is suitable for producing PE,HDPE,PP, PVC so on,plastic containers and bottles in all shapes are available, the max. product volume is up to 20L.
(2)Double station single die head design,Stable and efficient.
(3)Most components of the blow moulding machine are from famous world brand.
(4)Full automatic process with low power consumption,high efficiency,quick and safe operation,easy for maintenance.
(5)Multiple screw available for double layer or tranparent liquid lever line.
(6)Auto deflashing device available,can remove the extra parts of bottles.
(7)Auto lubricant system controlled by PLC.
(8)Special screw cut device available
ABLB90I full automatic plastic bottle blow molding machine
Main parts of Machine | Picture | Explanation |
Oil Pump | |
Oil pump From Japan YUKEN driving the machine |
Computer control system (PLC) |  |
Japanese Mitisubishi PLC
Used to control all electrial components and touch screen |
Parison controllor | |
MOOG parison Controllor Control the thickness of products |
Screw cutter device | |
This device is able to remove the extra top of gallons
|
| |
|
Electric Cabinet | |
This part is the full electric components of the machine |
The main components of machine
electronic parts | |
Name | Trader |
Micro computer control system | Japanese MITSUBISHI |
Temperature Controller | TAIWAN YANHUA PID |
Auxiliary Relay | OMRON |
contactor | Schneider from France |
Electric motor | Three phase 220V or 380V |
Power Source | TAIWAN MEANWELL |
Transducer | TAIDA FROM CHINA |
hydraulic parts | |
Name | Trader |
Oil pump | TAIWAN HIGH-TECH |
Valve | JAPAN YUKEN |
Oil pump and connection | JAPAN YUKEN |
Sealed part | HALLITE |
air control system | |
Name | Trader |
Cylinder | AIRTAC |
Air Valve | FESTO |
ABLB90I blow molding machine
Max. Product volume | 20 liters |
Out put capacity | 2160~2400pc/day |
Screw L/D ratio | 24 L/D |
Screw drive power | 45KW |
Screw heating capacity | 8 KW |
Output of HDPE | 128KG/H |
Oil pump drive power | 11 KW |
Clamping force | 108KN |
Max.size of mold | 240-660mm |
Mold stroke | 530 X 550mm |
Blowing pressure | 0.6 mpa |
Air Volume | 0.9 M³/MIN |
Cooling water pressure | 0.3mpa |
Water consumption | 90 L/MIN |
|
