Specifications
The insulating glass machinery is special equipment making aluminum groove type insulating glass...... Insulating glass machinery,The line is special equipment making aluminum groove type insulating glass. It can perform main functions such as washing and drying of insulating glass, positioning of aluminum frames, automatic one on one by flat press, setting level and shifting out of insulating glass in the process of making aluminum groove type insulating
glass. This line is high in efficiency, low in energy consumption, compact
in structure and easy to operate.
Features:
The whole machine is control by man-machine interface, to operate it and run P/L
easily. The sensor and machine's state is shown on the man-machine interface. When
meet troubles, it's easy to check it. The washing and water-box made by stainless
steel material, washing water system is circulating, the water-box has the
heating water equipment, automatic-feeding water equipment and heater with temperature-controlled.
The hydraulic pressure driving system controls transmission shaft,
insuring press the glass by setting time and pressure
Specifications:
1) Max. working size: 2,500 x 3,500mm
2) Min. working size: 200 x 450mm
3) Glass thickness: 3 - 25mm
4) Unit thickness: up to 60mm
5) Working speed:
a) Max. in washing section: 12m/min
b) Max. in accelerator: 50m/min
6) Brush: 3 pairs (low-e)
7) Power: 41.5kW, 380V/50Hz
