Help Center2014 Hot Selling Environmental Friendly Waste Plastic/rubber/tyres Pyrolysis Plant With Water Cooling System
Related Products
-
Good Quality High Efficiency Continuous Waste Tire Oil Pyrolysis Plant With No PollutionUS$ 345,000 - 380,000MOQ: 1 Set -
Best Quality Waste Tire Recycling Plant for Tire Pyrolysis Processing Into Tire OilUS$ 38,500 - 48,000MOQ: 1 Set
-
Leading Tire Recycling Machine Manufacturer Continuous Waste Tire Oil Pyrolysis PlantUS$ 345,000 - 380,000MOQ: 1 Set
-
Professional Manufacturer Good Tire Pyrolysis Technology Rational Price Waste Tire/plastic Pyrolysis MachineUS$ 38,500 - 48,000MOQ: 1 Set
-
20 Ton Capacity Fully Continuous Waste Tire Oil Pyrolysis PlantUS$ 345,000 - 380,000MOQ: 1 Set
This is our continuous waste tire/plastic/rubber/engine oil recycling pyrolysis machine and distillation machine
A. The model of our waste pyrolysis plant:
| No. | Reactor size(mm) |
Weight(MT) |
Volume(M3) |
Capacity( MT/D) |
1 |
2200*2200*6000 |
27 |
23 |
5 |
2 |
2200*2200*6600 |
29 |
25 |
6 |
3 |
2600*2600*6000 |
32 |
32 |
8 |
4 |
2600*2600*6600 |
34 |
35 |
9 |
5 |
2800*2800*6000 |
35 |
37 |
10 |
6 |
2800*2800*6600 |
38 |
41 |
12 |
B. The technical parameter of waste pyrolysis plant:
1 |
Model |
2200-6000 |
2200-6600 |
2600-6600 |
2800-6000 |
2800-6600 |
2 |
Capacity |
5 Ton/D |
6 Ton/D |
9 Ton/D |
10 Ton/D |
12 Ton/D |
3 |
Power |
8-11kw |
8-11kw |
12-17kw |
12-17kw |
12-17kw |
3 |
Material |
tyre/rubber/plastic |
||||
4 |
Structural form |
Horizontal rotation |
||||
5 |
Operating pressure |
Constant pressure |
||||
6 |
Reactor speed |
0.4 turn /minute |
||||
7 |
Mode of cooling |
Water cooling |
||||
8 |
Type of drive |
Internal gear drive |
||||
9 |
Noise dB(A) |
≤85 |
||||
10 |
Heating mode |
Direct heating |
||||
11 |
Dispatch period |
20 days after receiving the down payment |
||||
C. The main parts of waste pyrolysis plant:
1) Rotatable reactor 10)Cooling pool 19) Water pump
2) Machine cove 11)Induced Draft fan
3) Main machine base 12) Speed reduce
4) Oil-gas separator 13)Dust removing system
5) Catalyst tower 14)Waste gas burners
6) Coil cooling system 15)Blowers
7) Light oil tank 16)Electric cabinet
8) Heavy oil tank 17)Pressure meter
9) Water sealing tank 18)Temperature meter
D. The working process for waste pyrolysis plant( take plastic for example):
Waste plastic separation → automatic feed → catalytic cracking→ oil-water separation → cooling liquid → crude oil
→ flammable gas recovery → flammable gas combustion → desufuration and dust removal
E. 3D Pyrolysis plant of waste pyrolysis plant:
F. The delivery for waste pyrolysis plant:
G. The overseas installation for waste pyrolysis plant:
H. The factory of waste pyrolysis factory:
The machine itself cover 200-300 square meters(length 20-30M ; Width 15M).
Add raw material stay, carbon black stay, big oil tank zone ,workers rest room and simple office. At least 600-800square meters.
Warranty :
We guarantee of 1 year for the whole machine,except wear piece.
Installation:
We will give the foundation drawings to buyer after make the order and send engineer when buyer get the machine. The engineer mainly install the machine and training your workers.
After-sales service:
- 24 hours technical support by e-mail.
- Dispatch engineer within 10 days.
Catalyst formula:
We will supply the catalyst formula after you order the machine,you can buy them at your local.
