Aluminum Window Machine / Corner Key Cutting Machine,LJJ-CNC-500
It is a CNC full automatic machine specially used to cut corner connector.Saw blade is made from imported hard alloy driven by powerful motor.Adjustable clamping system in front ,back,up and down direction.closed protective covering makes the operation safe.spraying cooling system ensure fast cooling.Machine body adopts integral construction with good rigidity.Linear bearing motion pair gives less resistance force and ensures high processing accuracy.The PLC control and auto feeding system with high efficiency is suitable for large volume production.Extensive range of processing dimension and suitable material.
Power Supply |
As request |
Cutting motor power |
3kw |
Operation air pressure |
0.4-0.6Mpa |
Blade rotational speed |
3200 r/min |
Saw blade specification |
D=500mm d=30mm |
Cutting length |
Min3mm Max200mm |
Contour dimension(L*W*H) |
6300*1800*1600mm |
Cutting (width*height) |
140×280mm |
Machine weight(about) |
650kg |
