Home > Manufacturing & Processing Machinery > Crane > Truck Crane > China XCT25E XCMG 25 Ton Crane Mobile Crane Seewon

China XCT25E XCMG 25 Ton Crane Mobile Crane Seewon

Name: China XCT25E XCMG 25 Ton Crane Mobile Crane Seewon
Brand: XCMG
SKU: 131179697
Availability: InStock

China XCT25E XCMG 25 Ton Crane Mobile Crane Seewon thumbnail-1

China XCT25E XCMG 25 Ton Crane Mobile Crane Seewon photo-1

US$ 130,000 - 135,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Application:

Construction

Rated Loading Capacity:

4~16TON

Contact Supplier Request Quote Chat Now

Full Luck Enterprises Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Construction

Rated Loading Capacity 4~16TON

Rated Lifting Moment 1764kN.M

Max. Lifting Load 50ton

Max. Lifting Height 50m

Span 7.6m

Brand Name XCMG

Model Number XCT25E

Certification ISO CE SGS

Warranty 24 Months

After-sales Service Provided Overseas service center available

Product Description

Dynamic Forms					Disel
Rated load				kg	16000
Load Centre distance				mm	600
Maximum lifting height				mm	3500
Free lifting height				mm	0
Fork dimensions				mm	1800×180×100
Gate inclination angle				deg	Front 6 back12
Fork overhang				mm	968
Distance between rear suspension				mm	840
Dimensions	The total length			mm	7410
	Total width			mm	2752
	Door frame not lift height			mm	3675
	Safe frame height			mm	3566
Gear racks ( fork ) height				mm	1410
Minimum turning radius				mm	5300
Minimum right angle aisle width				mm	8268
Max traveling speed ( loaded / unloaded )				Km/h	22/27
Max lifting speed ( unloaded / loaded )				mm/s	300/280
Maximum climbing angle				%	20
Gross tonnage				kg	22000
Tyre		The front wheel			12.00-24-20PR
		Rear wheel
Tread		The front wheel		mm	1895
		Rear wheel		mm	2120
Wheelbase				mm	3800
Minimum ground clearance			Door frame	mm	330
			Frame	mm	335
Model					YuchaiYC6A175Z-T10
Rated power				kw	128
Rated torque				N·m/r/min	670/1500-1800
Number of cylinders					6
Displacement				L	7.252
Fuel tank capacity				ltr	350

Certifications

Our Company

FULLLUCK

FULLLUCK is one of the leading truck and construction equipment distributors and exporter in China. FULLLUCK cooperates with leading truck manufactures and suppliers of brand name VOLVO, RENAULT TRUCK, SINOTRUCK , LONKING and ISUZU.
Focus on the oversea market development, FULLLUCK is the professional exporter for heavy duty trucks, construction equipments, and spare parts in China.To face global markets sales, except complete equipment sales, we pay more attention to technology consultation and after-sale service. Technician overseas market technical guidance and training service, complete and scientific spare parts supply system are provided by us to meet different purchasing requirements from clients.
For secondhand construction equipment exportation business, we provide service including complete painting for equipment, wire sorting for equipment, quick-wear parts sales and so on.
