Home > Manufacturing & Processing Machinery > Crane > Truck Crane > China QY25B.5 XCMG 25 Ton China Hydraulic Crane Truck

China QY25B.5 XCMG 25 Ton China Hydraulic Crane Truck

Name: China QY25B.5 XCMG 25 Ton China Hydraulic Crane Truck
Brand: XCMG
SKU: 131179717

China QY25B.5 XCMG 25 Ton China Hydraulic Crane Truck thumbnail-1

China QY25B.5 XCMG 25 Ton China Hydraulic Crane Truck photo-1

US$ 75,000 - 76,000 MOQ: 1 Unit

Key Specifications

Get Latest Price

Condition:

New

Application:

Construction

Rated Loading Capacity:

4~16TON

Contact Supplier Request Quote Chat Now

Full Luck Enterprises Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application Construction

Rated Loading Capacity 4~16TON

Rated Lifting Moment 1764kN.M

Max. Lifting Load 25ton

Max. Lifting Height 50m

Span 7.6m

Brand Name XCMG

Model Number QY25B.5

Certification ISO CE SGS

Warranty 24 Months

After-sales Service Provided Overseas service center available

Product Description

Dimension	Unit	QY25B.5
Overall length	mm	12990
Overall width	mm	2500
Overall height	mm	3430
Weight
Total weight in travel	kg	29000
Front axle load	kg	6970
Rear axle load	kg	22030
Power
Engine model		SC8DK260Q3
Engine rated power	kW/(r/min)	192/2200
Engine rated torque	N.m/(r/min)	1000/1400
Travel
Max. travel speed	km/h	75
Min. turning diameter	m	20
Min. ground clearance	mm	272
Approach angle	°	16
Departure angle	°	13
Max. grade ability	%	30
Fuel consumption for 100km	L	40
Main performance
Max. rated total lifting capacity	t	25
Min. rated working radius	mm	3000
Turning radius at turntable tail	m	3.450
Max. lifting torque	kN.m	1010
Base boom	m	10.85
Fully extended boom	m	34.19
Fully extended boom+jib	m	42.3
Longitudinal outrigger span	m	5
Lateral outrigger span	m	6
Working speed
Boom luffing time	s	75
Boom full extension time	s	100
Max. swing speed	r/min	3
Max. speed of main winch (single rope)	m/min	120
Max. speed of aux. winch (single rope)	m/min	120

Certifications

Our Company

FULLLUCK

FULLLUCK is one of the leading truck and construction equipment distributors and exporter in China. FULLLUCK cooperates with leading truck manufactures and suppliers of brand name VOLVO, RENAULT TRUCK, SINOTRUCK , LONKING and ISUZU.
Focus on the oversea market development, FULLLUCK is the professional exporter for heavy duty trucks, construction equipments, and spare parts in China.To face global markets sales, except complete equipment sales, we pay more attention to technology consultation and after-sale service. Technician overseas market technical guidance and training service, complete and scientific spare parts supply system are provided by us to meet different purchasing requirements from clients.
For secondhand construction equipment exportation business, we provide service including complete painting for equipment, wire sorting for equipment, quick-wear parts sales and so on.
