Solar Gird-connected Inverter

Name: Solar Gird-connected Inverter
Brand: KINGWOOD
SKU: 131159945
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

KINGWOOD

Model Number:

DA-10KS

Guangdong Kingwood Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name KINGWOOD

Model Number DA-10KS

Specifications

Using the fifth generation of Mitsubishi IPM Module, significantly improve system efficiency

Features:

1. Using the fifth generation of Mitsubishi IPM Module, significantly improve system efficiency

2. MPPT self-optimizing technology to maximize the system capacity

3. Multi-language LCD display features, can be set up freely

4. Can choose a variety of communications interfaces, can handily achieve monitor of the host computer

5. Strong protection function, greater reliability of the system

6. Wide range of the DC input voltage

7. Human interface, can set the various operating parameters by pressing a button

8. Achieve to operate the combination of multiple inverter, simplify the design of power station

9. The cabinet using the IP65 protection grade, stainless steel enclosure, suitable for outdoor installation

10. With waterproof-line terminals

11. With CE Certificate

Technical parameters:

Technical Data	DA-10KS
Isolation method	With Industrial Frequency Transformer
Max. Power Match	11Kwp
Max. DC Input Voltage	450V
MPPT Range	200~380V
Connection Method of Battery Panels	By Terminals
Can access numbers of tandem	50A
Max. DC Input Current	10KW
Reted AC Output Power	<3%(rated power)
Total Harmonic Distortion(THD)	>0.99
Power Factor	>0.99
Max. Frequency	94.5%
Europe Efficiency	93.5%
AC Output Voltage Range (three phase)	330~450VAC
Output Frequency Range	47~51.5Hz/57~61.5Hz
Power Consumtion at night	0W
Communication Interface	RS485/Ethernet
Internal Protection	IP20(inside)
Operation Temperature	-20~+40
Noise	<60dB
Cooling Method	Air-cool
Dimension(Wide×High×Deep)	530mm×900mm×500mm
Weight	150kg
