Home > Electrical & Electronics > Power Supply & Distribution > Switching Power Supply > Switching Power Supply for Telecommunication Use

Switching Power Supply for Telecommunication Use

Name: Switching Power Supply for Telecommunication Use
Brand: KINGWOOD
SKU: 131159965
Availability: InStock

Switching Power Supply for Telecommunication Use thumbnail-1

Switching Power Supply for Telecommunication Use photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

KINGWOOD

Model Number:

AD4850

Contact Supplier Request Quote Chat Now

Guangdong Kingwood Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guanghzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name KINGWOOD

Model Number AD4850

Input Voltage 130~300V

Output Voltage 40~60V (adjustable)

Output Power 2400W

Output Current 50~55A

Specifications

It use the most advanced PWM technology and the most stable and reliable circuit topology

Introduction:

This series of high-frequency switching power supply are designed for a variety of communications electronics equipment, such as program-controlled switches, microwave equipment, optical fiber communication equipment etc. which are high efficiency, high performance, high stability, high reliability, and which use the most advanced PWM technology and the most stable and reliable circuit topology.

The series are small size, light weight, high efficiency, wide operating temperature range, strong anti-jamming capability, fast dynamic response, high stability, smal noise ripple, and with strong protection features, which apply to CNC machine tools, data-processing and other equipment, and which can be used as charging and discharging equipment for battery.

Features:

1. High precision regulators

2. Fast dynamic response

3. Low output noise

4. Strong anti-interference ability

5. Wide operating temperature range

6. Strong protection function

7. With N +1 module composite structure

Technique Parameters:

Technical Data		Parameters
AC Input	Voltage	130V~300V (single-phase three wire system)
	Frequency	5~65 Hz
	Efficiency	≥90%
DC Output	Power	2400W (max)
	Voltage Range	40~60V (adjustable)
	Current-limiting	50~55A
	Load Regulation	≤±0.4%
	Electricity Grid Regulation	≤±0.1%
	Accuracy of Voltage Stabilization	≤±0.5%
	Phone Scale Noise Voltage	≤2mV
	Broad Frequency Noise Voltage	3.4 kHz~150kHz≤50 mV 0.15 kHz~30kHz≤20 mV
	Discrete Frequency Noise Voltage	3.4 kHz~150kHz≤5 mV 150kHz~200kHz≤3 mV 200kHz~500kHz≤2 mV 0.5kHz~30kHz≤1mV
	Peak - Peak Noise Voltage	≤200mV(20MHz)
Insulation Strength	Input-Output	2000VAC
	Input-Shell	1500VAC
	Output-Shell	500VAC
Leakage Current	<1.5mA (220V AC Input)
Safety Regulation	Meet the requirements of EN60950
EMC	Design refer to FCC Part15 J Conduction Class A
Environment	Working Temperature	-15~+50
	Storage Temperature	-40~+85
	Humidity	10%~90%RH
MTBF	≥100000 Hrs.
Cooling Method	Forced air-cooled: 65CFM (Internal DC fan), when the temperature of radiator is over 85, the output begins to derate; when the temperature of radiator is up to 95, the output will derate to 60%; when the the temperature of radiator is over 95, the device will close.
Protection	Input Overload	Dc<130±5V, device will close automatically
	Input Underload	Dc>300±5V, device will close automatically
	Output Overload	Vdc≥60±1V, device will alarm to close, which need to manually re-start after the fault removed
	Output Short-circuit	Retraction limiting, recover automatically after the fault removed.
	Over temperature	When the temperature of the case is (85±5), the rectifier begins to derate; when the temperature is up to (95±5), the output will derate to 60%; when the temperature is over (95±5), the device will close and alarm.
