2016 new wifi 1080p 5 camera wireless security system

Name: 2016 new wifi 1080p 5 camera wireless security system
Brand: GAOZHI
Price: USD $226 - 263 / Set

FOB Price

USD $226 - $263 / Set

5 Sets(Min.Order)

Supply Ability 10000 Set / Sets per Month
Port SHENZHEN
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

GAOZHI

Model Number:

GZ-KW44-B62W2

Product Description

2016 new wifi 1080p 5 camera wireless security system

Hot sale security camera system !!
4CH AHD DVR Kits	4CH IP camera NVR kits

Product Description

Specification

1080P WiFi IR Bullet IP Camera

Model no.: GZ-IPC-B6206-W with AR 1021wifi model, 2 antennas

Pictures

Key features

• 1/3" 1080P progressive scan CMOS
• H.264 High profile encoding
• Max. 30fps@1080P
• Supports IR-CUT filter switch to achieve day and night monitoring
• Metal housing, Ingress protection IP66
• Max. IR LEDs distance 20m
• Onvif V2.1 protocol
• IEEE802.11 b/g/n

Camera	Image Sensor	1/3" 1080P CMOS
	Effective Pixels	1920 (H)x1080(V)
	Min. Illumination	Color: 0. 05LUX/F1.8, B/W: 0Lux (IR on)
	S/N Ratio	>50dB
	Backlight Compensation	BLC
	WDR	Digital WDR
	Noise Reduction	3D DNR
	Gain Control	Auto/Manual
	Day/Night	Auto(ICR) / Color / B/W
	White Balance	Auto
	Electronic Shutter Speed	Auto/Manual 1/50~1/10000
	IR distance	IR distance 20 Meters
Lens	Focal Length	3.6 mm Lens
	Max Aperture	F1.8
	Focus control	Fixed
	Angle of View	70°@6mm
Video	Video Compression	H.264 High Profile / JPEG Snapshot
	Resolution	Main Stream:1080P(19201080) Sub Stream: 352288
	Video Bitrates	1024Kbps ~ 6144Kbps
	Video Frame Rate	Default 15fps @1080P, Max. 30fps@1080P
Audio	Compression	ADPCM
	Interface	embedded mic in
Wifi parameters	Wifi standard	ieee 802.11 a/b/g/n
	Frequency range	2.4GHZ/5GHZ
	Security	64/128-bit WEP, WPA/WPA2,WPA-PSK/WPA2-PSK,WPS
	Transmission rate	11b:11Mbps, 11a: 54Mbps, 11g:54Mbps, 11n:150Mbps
	Transmission distance	testing the communication distance bewtenn Wifi NVR WN3000 and Wifi IPC-B6207-W, WN3000 connected with router by cable : open environment 90 meters. Wall test, 4 walls, 33 meters
Network	Ethernet	RJ-45 (10/100Base-T)
	Wi-Fi	Support, IEEE802.11 b/g/n
	Network Protocol	IPv4, HTTP, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Cloud
	Network Preview	Web browser view, including IE,Chrome,Firefox
	Smart Phone	Supports iPhone,iPad, Android phone,pad,Windows Mobile phone.
	Compatibility	Onvif V2.1
	Max. User Access	12 Users
General	Power Supply	DC12V
	Power Consumption	<6W
	Working Environment	-10℃~+55℃(14°F~131°F),10%~90%
	Ingress Protection	IP66
	Dimensions	Φ65 x 188mm
	Weight	360g

Model no.: GZ-NVR-WN3000

Main Chip: Hisilicon 3520D

Pictures

Key features

• 4CH 1080P/720P Wifi IP camera input;
• 1/4CH playback;
• embeded ieee802.11 b/g/n 2x2 WiFi router AP,Max 300Mbps bandwidth;
•Wifi connect PnP,no need to set WiFi SSID;
• Supports VGA (Maximum HD 1080p) , HDMI (Maximum HD 1080p) output;
• 2 USB2.0 ports, 1SATA 3.0 HDD port(up to 4000G);
• Supports smart phone real time remotely monitoring, such as iPhone,Android;
• Provide IE Activex,CMS,StreamView APP
• Support P2P

System	GUI	16-bit True Color
	Operating System	Embedded Linux OS
	Password security	Multi-level users management, 1 Admin + 19 Users
A/V Input	Video Input	720P/1080P WiFi IP Camera x4
	Audio Input	NO
A/V Output	Decoding resolution	720P/1080P
	VGA output	1024768,1280720,1280800,12801024,1440900,19201080P (1080P)
	HDMI output	1024768,1280720,1280800,12801024,1440900,19201080P (1080P)
	Audio output	1ch RCA
	Playback resolution	720P/1080P
	Synchronous playback	4CH
HDD	SATA Devices	1 x SATA HDD
	Maximum capacity	4TB
	External HDD	1 x Esata, e-sata as storage function.
External Interface	USB Connector	2 x USB2.0
	Serial Interface	NO
	2 way audio (voice talk)	NO
	Alarm input/output	Optional
	Network Interface	RJ 45,10M/100 M Ethernet, ieee802.11 b/g/n support AP or Station Mode,dual antenna
Network	Network protocol	TCP/IP, SMTP, HTTP, DHCP, PPPoE, NTP, DDNS,UPnP,FTP,RTSP,Onvif,P2P
	Mobile Device	iPhone, iPad,Android Phone, Android Pad
	System Upgrade	Supports USB update
	Remote Software	StreamView APP, IE Browser,Google Chrome Browser,Firefox Browser
General	Power Supply	Input 100~240V, 12V 2A
	Consumption	<10W without HDD&PoE
	Working temperature	-10℃~+55℃(14°F~131°F)
	Working humidity	10%~90%
	Dimension ( mm )	260(W) x 41(H) x 230(D)
	Weight ( w/o HDD/DVD±RW )	1.6 kg

What's included

BOM For 4CH 2MP Wifi kit, Based on R260 housing
BOM For 4CH 2MP Wifi kit, Based on R260 housing
NO.	Items	specification	Quantity	1. Economy kit	2. Standard kit	3.Super kit
1	WN3000 -with Wifi	4CH 2Mega @Hisilicon 3520D	1	√	√	√
2	Original color box of NVR	with foam	1	√	√	√
3	Adapter of NVR	12V-2A	1	√	√	√
4	Dryer bags		1	√	√	√
5	Software CD	3.5"	1	√	√	√
6	Remote Control with battery		1	√	√	√
7	USB Mouse(Red light)	USB Mouse with red light	1	√	√	√
8	antennas of NVR		2	√	√	√
9	E-sata		1	√	√	√
10	Ethernet Cable	3.5ft / 1m	1	√	√	√
11	HDMI cable	6.5ft / 2m	1	√	√	√
12	Hard Disk		1			√
15	2MP Bullet Wifi IP Camera (Model:IPC-B6206-W2)	OV2710 +GM8136S	4	√	√	√
16	Adapter of cameras	12V-1A	4	√	√	√
17	18m power cable		4		√	√
18	antennas of cameras		8	√	√	√
19	Original color box of Camera	1 package with 4 cameras	4	√	√	√
20	Screw installation package		4	√	√	√
21	Outer box		1	√	√	√
