Flexible solar panel 50-200W in manufacturing machine of cells in panel
Rigorous quality control meeting the highest international standards
High-transmissivity low-iron tempered glass, strong aluminium frame
Using UV-resistant silicon
ISO 9001:2008 and ISO 14001:2004
IEC61215, IEC61730, Safety Class Inconformity to CE
1. Features
1. Aesthetic appearance with excellent efficiency based on innovative photovoltaic technologies
2. Strong frame, passing mechanical load test of 5400Pa, instead of the normal 2400Pa, to withstand heavier snow load and higher wind-pressure
3. Assembled by high efficiency crystalline silicon cells
4. The sturdy, anodized aluminum frame allows the modules to be mounted on a variety of standard racking systems and to withstand harshest conditions
5. High transmission low iron tempered glass(self-cleanning galss is an other option), strong mechanical resistance, which could be capable of taking the pressure of 5400 pa.
6. Ultra reliable bypass diodes prevent damage from overheating due to shaded or defective cells .
7. High-quality imported polycrystalline or monocrystalline solarcells;high-rigidity tempered glass, excellent light transmittance and outputperformance;
8. Surface treated with reflection-reducing process, increasing the light absorption.Back sealed with anti-aging EVA, resistant from moisture and corrosion.
9. The efficiency of monocrystalline solar cell is over 17%, polycrystallinepanel is over 16%.
10. 25 years life. The power decline less than 10% within 10 years, 20% within 20 years.
We supply the Flashing list based on the container quantity order . and each panel and packing comes with barcode . OEM order are welcome . send us the inquiry right now , we will get back to you in 24hours . enjoy our 25hours/days service . one more hours from Dreams. lol.
2. Advantages:
-High brightness, energy saving, environmental-friendly.
-Advanced technology, exquisite workmanship, and proprietary design.
-Easy installation, free maintenance.
-Quality in priority, clients the upmost.
3. Electrical Characteristics
| Item No. | SO200P-18 |
| Max Power (Wp) | 200W |
| Optimum Working Voltage (Vm) | 26.2V |
| Optimum Working Current ( Im) | 7.63A |
| Open-Circuit Voltage (Voc) | 33.4V |
| Short-Circuit Current (Isc) | 8.12A |
| Packing Measurement (W*L*H) | 1515*1022 |
| Net Weight | 17KG |
All model display:
| Monocrystalline Silicon Solar panels | |||||||||||
| Model | Maximum power(Pm) | Open circuit voltage(Voc) | Short circuit current(Isc) | Optimum operating voltage(Vmp) | Optimum operating current(Imp) | Module Dimension H*W*D(mm) | MOQ(W) | 20FT | 40FT | Price EXW SZ(USD/W) | Delivery Date |
| TB-230W-M | 230W | 43.4V | 7.26A | 35.4V | 7.06A | 1954*990*50 | 1000w | 174PCS | 360PCS | usd0.98/W | 15 days |
| TB-200W-M | 200W | 33.0V | 8.19A | 26.4V | 7.58A | 1490*990*50 | 1000w | 298PCS | 634PCS | usd0.98/W | 15 days |
| TB-175W-M | 175W | 43.8V | 5.21A | 35.8V | 4.91A | 1330*995*50 | 1000w | 335PCS | 721PCS | usd0.98/W | 15 days |
| TB-160W-M | 160W | 42.8V | 4.58A | 35.2V | 4.26A | 1330*995*50 | 1000w | 340PCS | 726PCS | usd0.98/W | 15 days |
| TB-150W-M | 150W | 42.8V | 4.58A | 35.2V | 4.26A | 1330*995*50 | 1000w | 340PCS | 726PCS | usd0.98/W | 15 days |
| TB-130W-M | 130W | 21.6V | 8.08A | 18V | 7.22A | 1471*666*35 | 1000w | 700PCS | 1600PCS | usd0.98/W | 15 days |
| TB-100W-M | 100W | 21.6V | 6.2A | 18V | 5.56A | 995*808*35 | 1000w | 786PCS | 1690PCS | usd0.98/W | 15 days |
| TB-80W-M | 80W | 21.6V | 4.76A | 18V | 4.44A | 1206*535*35 | 1000w | 980PCS | 2100PCS | usd0.98/W | 15 days |
| TB-50W-M | 50W | 21.6V | 3.04A | 18V | 2.78A | 765*535*35 | 1000w | 1400PCS | 2100PCS | usd0.98/W | 15 days |
| TB-40W-M | 40W | 21.6V | 2.4A | 18V | 2.22A | 655*535*25 | 1000w | 2520PCS | 5400PCS | usd0.98/W | 15 days |
| TB-30W-M | 30W | 21.6V | 1.82A | 18V | 1.67A | 666*420*25 | 1000w | 2800PCS | 5700PCS | usd0.98/W | 15 days |
| TB-20W-M | 20W | 21.6V | 1.23A | 18V | 1.11A | 535*345*25 | 1000w | 3200PCS | 7100PCS | usd0.98/W | 15 days |
| TB-15W-M | 15W | 21.6V | 0.95A | 17.2V | 0.88A | 500*400*25 | 1000w | 3250PCS | 7150PCS | usd0.98/W | 15 days |
| TB-10W-M | 10W | 21.6V | 0.63A | 17.2V | 0.58A | 340*290*23 | 1000w | 3300PCS | 7200PCS | usd0.98/W | 15 days |
| TB-5W-M | 5W | 21.6V | 0.31A | 17.2V | 0.28A | 285*195*25 | 1000w | 3300PCS | 7200PCS | usd0.98/W | 15 days |
4. Why choose us?
A. Professional Manufacturers Of Mono & Poly Silicon PV Module
B. High Conversion Efficiency Solar Module
C. High transmission rate and low iron tempered glass
D. Anti-aging EVA, high frame resistant TPT to laminate and anodized aluminum alloy frame
E. Long life, Easy installation, high wind and hail impact resistance etc advantage.
F. Be resistant to atmospheric exposure and effects of delamination
G. Strict quality control and power classification of modules
H. Ready to use with junction box, cabling and connectors
I. ISO9001:2008 , ISO14001:2007, OHSAS18001: 2007 , CE , TUV IEC/EN61215 IEC/EN61730
J.25years Warranty , 90% of original efficiency in 10years, and 80% in 25years.
5. Detailed pictures:
Application
Customer Services
Please contact us through email to me, we will assist you in any way possible and aim to answer all emails within 24-48 hours.
Payment Terms:
- 1. T/T ,Western Union,Money Gram.
- 2. We will arrange the products and shipment within 3-7 working days after receive the payment
Lead Time:
- 1.Sample orders will be delivered from our factory within 7 working days.
- 2.General orders will be delivered from our factory within 7-15 working days.
- 3.Big orders will be delivered from our factory within 15-25 working days at most.
Shipment
- 1.By EMS,DHL,FedEx,TNT,UPS or other express.
- 2.By our forwarding agent(by air or by sea).
- 3.By your own forwarding agent.
- 4.By domestic forwarding agents to any city in China.
-
Packaging & Shipping
