[ DATAN ] Reformed! gantry cnc milling machine for sale
[ DATAN ] Reformed! gantry cnc milling machine for sale
Advantage and history — 15 years best hot selling products.
- DATAN always keep leading levels in china, In 1999, DATAN pioneered research and production of TX32 promotes the development of China's manufacturing industry.
- Follow the DATAN and a few well-known machine brand, Hvae more factories start research and production cnc machine,From now on, China entered the automation manufacture era.
1. Machine structure
- this series adopted wide guide rail, make machine have good wear-resistant capacity.
- Made of resin sand that dealt with electric furnace smelting ,which bestows the machine with a high rigidity.
- The adoption of ball screws with bearing at both end has ensured the machine a stable accuracy.
2. Machine configurations
- With special design of modularization, According to the different processing requirements of customers, the use of different configurations.
- The control setting can add extra electrical indexing head or NC indexing head ,electric rotary table or NC rotary table and A.T. C system.
3. Machine process
- Suitable for drilling ,hole-expansion ,reaming ,bevel edge ,and tapping, for surface milling, step plane ,slope ,and milling groove , for cutting and milling curve ,curve surface and cam.
- Have the function of stepless speed and automatic speed change to gain large torque with low speed, suitable for processing thick cutting depth and larger-diameter hole.
| Model No. | TX 25 | TX 32 | |
| Worktable | mm | 700mm×260mm | 850mm×320mm |
| Max load on worktable | kg | 100kg | 150kg |
| X, Y, Z, axis travel | mm | 400×260×260 | 500×300×360 |
| Spindle nose to worktable | mm | 120mm-380mm | 400mm |
| Spindle centerline to column | mm | 260mm | 300mm |
| Spindle Taper | Mt4 | 7/24 Taper No.40 | |
| Spindle Speed | rpm | 150-3000/300-6000 | 150-3000/300-6000 |
| Max gearbox ratio | 1:1 / 1:2 | 1:1 / 1:2 / 1:4 / 1:8 | |
| Max torque | N.m | 10/20N.m | 20 / 40 /80 / 160N.m |
| Spindle motor power | KW | 1.5KW variable-frequency motor | 3KW variable-frequency motor |
| Tool change type | Manual/semi-automatic | Manual/semi-automatic | |
| Mini display unit | mm | 0.01/0.001mm | 0.01/0.001mm |
| Triaxial motor (torque/power) | N.m/kw | 16N.m/1kw servo motor | 16N.m/1kw servo motor |
| Ball screw types | Φ25×P10 ball screw | Φ32×P6 ball screw | |
| Processing for | Drilling, tapping, boring and milling with high speed | Drilling, tapping, boring and milling with high speed | |
| Cover | Half(or full) cover splash guard | Half(or full) cover splash guard | |
| Machine weight | kg | 1600kg | 2300kg |
| Overall dimension (L*W*H) | mm | 1300×1500×1850 | 2000×2000×2100 |
gantry cnc milling machine for sale
gantry cnc milling machine for sale
A. Confirm the purchase
1.Sign the contract
After the business contract signed standards,When receive your 30% deposit from the company, contract comes into force,Your order will be made by your business manager and engineer the entire tracking for you.
2.Arrange production
The sales manager to fax receiving your sign a good contract,Start the system production process for production.
Cnc milling machine is usually within 15 days, vertical cnc machining center is within 25 days, gantry type machining center is within 45 days, if you need to add special configuration, the delivery time will be postponed.
3.The delivery
Production is completed in the process of delivery,Before the start,According to the industry standard,The remaining 70% balance need to receive you,It is recommended that you buy wooden frame outer packing,Prevent damage produced in the process of collision.
4. Check the acceptance
- keep your phone open,Convenient to contact you forwarder company,Receive machine,please check:
- If the outer packing damage, leakage erc, and if the goods damaged;
- Check the packing list,the product literature and warranty cards if they is integrity;
- Examine the content of the packing list,the product quantity to both consistent,and accessories;
- Machine details if they are normal, If have the trace of replacement and maintenance, If have other effects use of the problem.
If happens above declare,please take pictures and contact us immediately.
B.Training and maintenance
1.In order to you more efficiency for production,At the end of the contract is signed,You can send someone to my company for professional CNC programming and operation training.
2.Warranty is 12 months which begins from the day when the machine has arrived at the importer’s port.
If the device can 't work normally,My company after received your notice, within 24 hours,We will send engineers to your factory for processing,If it is artificial damage,The Need to charge a cost.
Warranty expires,Machine tools are still support maintenance.
3.Each cnc machine leaving the factory will be along with related series or model the English instructions including maintenance manual and operation manual. Attached documentations may also include cnc controller instruction, parts instruction you bought.
gantry cnc milling machine for sale
——————————————————————————————————————
