Home > Manufacturing & Processing Machinery > Rubber Machinery > Rubber Raw Material Machinery > Two Rolls Open Mixing Mill

Two Rolls Open Mixing Mill

Name: Two Rolls Open Mixing Mill
Brand: Taizheng Machinery
SKU: 131003841
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Open Mixing Mill

Place of Origin:

Fujian, China

Contact Supplier Request Quote Chat Now

Jinjiang Taizheng Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

XIAMEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Open Mixing Mill

Place of Origin Fujian, China

Brand Name Taizheng Machinery

Voltage 220v,380v,415v,440v

Power(W) 90/110

Dimension(L*W*H) 6300*2300*2000mm

Weight 18ton

Certification AAA certificates

Warranty one year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Roller length:1500mm
2.For rubber or plastic
3.Rollers are made of chilled cast iron

Two rolls open mixing mill

Overview:

This machine is mainly used in Rubber & Plastic product factory for Natural Rubber Mixing(plasticating),Raw Rubber and Compounds mixing,rubber warm-up mixing and pressing sheet.

Machine parameters:

Model	XK-250	XK-400	XK-450	XK-550
Roller diameter (mm)	250	400	450	550
Roller working length(mm)	680	1000	1200	1500
Front roller working speed (m/min)	14.2	24.2/21.5	27.3/24.3	28.3/29.2
Speed ratio of front & rear roller	1:1.21	1:1.27	1:1.27	1:1.29
Max.roller gap (mm)	8	10	10	15
Nip adjustment	Manual	Manual	Manual	Manual or electric
Batching capacity (kg)	10-15	25-35	30-50	50-60
Main motor power (kw)	15	45	55/75	90/110
Main motor revolving speed(r/min)	980	980	980	740/980
Gear box ratio	45	40/45	40/45	35/45
Machine dimension (mm)	3400x1300 x1600	4400x2000 x1900	5000x2200 x2000	5500x2300 x2200
Machine weight (kg)	4200	9000	11500	20000

Main features:

1. The speed reducer is the hard-tooth surface gear reducer,

which is durable and with low noise.

2. The roller adopts the vanadium titanium metal alloy chilled cast iron and its surface is hard and wear-proof with long service life. The internal cavity is processed to make temperature well proportioned to the roller surface.

3. The machine is also equipped with an emergency brake device. When an emergency arises, just push the emergency stop button, the machine will stop immediately. It is safe and reliable.

4. The machine is equipped with an overload protection device to prevent the main components from being damaged.

5. The transmission system adopts a hardened tooth-surface reducer, which has a compact structure with higher transmission efficiency, lower noise and longer service life.

6. The base frame is a whole framework, which is convenient for installation.

7. The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.

Machine photos:

Exhition we participated in:

Our factory view:

FAQ:

Q: What is your MOQ of this item?

A: 1 set per style

Q: What is the lead time?

A: It depends on your order quantity.

Q: Is it all right to make customer's own brand name?

A: That’s all right to make your own brand name.

Q: Where is your Loading Port?

A: Xiamen.China Port.

Q: What are your payment terms?

A: 30% deposit and balance T/T before shippment or L/C at sight

Q: What is your company's available production capacity?

A: Usually 40 sets monthly.

Exported countries

Currently, we are pleased to export our products to clients throughout the world, including India, Indonesia, Brazil, Malaysia, Korea, Peru and so on.

We'll offer you the quotation as soon as possible once received your inquiry,so please don't hesitate to contact us. We can produce the product under your brand name, also the size can be changed as your requirement. We confirm that quality and serve at the first place!
