Help CenterDigital Satellite TV Receiver, HD MPEG4 DVB-T With PVR, Support USB2.0
Related Products
-
FTA HD DVB-T HDMI , HDVB8701NegotiableMOQ: 200 Pieces -
Russia HD Mini Scart MPEG4 DVB-T Set Top Box With Tuner ManufactureNegotiableMOQ: 1000 Pieces
-
2011 Mini SD DVB-T With High Quality and Best PriceNegotiableMOQ: 1000 Pieces
-
Mpeg4 Tuner Dvb T,HDVB8609 Mini ScartUS$ 18 - 19MOQ: 1000 Pieces
-
HD DVB-T STB (HDVB8605) for Europe MarketUS$ 20 - 24MOQ: 10 Pieces
Specifications
1.HDTV(1080p)/SDTV MPEG2 & MPEG4 H.264 AAC+ Compliant2.Support USB2.0, with PVR fuction
3.More than 10 language
4.CE & ROHS
Key Features:
1. HDTV(1080p)/SDTV MPEG2 & MPEG4 H.264 AAC+ Compliant
2. Support PVR function and multimedia playback(MP3/MP4/JPEG/AVI etc) via USB2.0
3. MPEG2(), MPEG4 , MPEG4 AVC/H.264 decoding
4. Video output resolution: 480i/576i/480p/576p/720p/1080i
5. Video decoder up to
6. Audio decoding: MPEG 1/2 Layer I&II, MPEG4 AAC/HE-AAC V2(AAC+), Dolby AC-3/AC3+(optional)
7. OSD language: English, Czech, Danish, French, German, Italian, Portuguese, Spanish, Swedish etc
8. Aspect ratio: Auto, 4:3 Full, 4:3 Pan&Scan, 4:3 Letter Box, 16:9 Wide Screen
9. Support 7-day Electronic Program Guide(EPG)
10. Support teletext/subtitle/audio language selection
11. Capacity for storing up to 1000 channels of TV and radio program
12. Outputs: HDMI1.3, SCART, CVBS, SPDIF(Coaxial)
13. Auto/manual channel search
14. PAL/NTSC auto conversion
15. Software upgrade via USB or OTA
16. Keys: POWER, VOL+/-, CH+/-, MENU, OK
17. 4-digit LED indicator
18. Standby consumption less than 0.85W (True Standby)
Specification
Tuner & Channel
Input Connector IEC-169-2 (IEC-type) Female
Frequency Range 48~862MHz
RF Loop Connector IEC, Male
Signal Level: -10 to -70 dBm
Demodulation: OFDM
Mode 2K, 8K
FEC Mode 1/2, 2/3, 3/4, 5/6,7/8
Guard Intervals 1/4, 1/8, 1/16, 1/32
MPEG Transport Stream A/V Decoding
Transport Stream MPEG-2 ISO/IEC 13818 Transport Stream Specification
Profile Level MPEG-2 ,
MPEG-4 AVC/H.264
Aspect Ratio Auto, 4:3 Full, 4:3 Pan&Scan,4:3 Letter Box, 16:9 Wide Screen
Video Resolution 480i/576i/480p/576p/720p/1080i
Audio Decoding MPEG 1/2 Layer I&II, MPEG4 AAC/HE-AAC V2(AAC+),
Dolby AC-3/AC3+(optional)
Audio Mode Single channel/dual channel/joint stereo/stereo
Audio/Video/Data In/Out
Video RCA-Type (CVBS), SCART, HDMI
Audio Audio L/R, SPDIF (Digital Audio Output)
Data USB2.0
Power Supply
Input Voltage AC 90~ 250 V, 50/60 Hz
Type SMPS
Power Consumption Max 9W
Protection Separate internal fuse
Physical Specification
Size 259 x 38 x 202mm
Weight (Net) 1.98kg
Operating Temperature 0°C to +45°C
